| SPECIFICATIONS | |
| Brand | ASUS |
| Model | PRIME B350M-A |
| Series | PRIME B350M-A |
| CPU | AM4 socket for AMD Ryzen/7th Generation A-series/Athlon Processors | Supports CPU up to 8 cores |
| Chipset | AMD B350 Chipset |
| Form Factor | Micro-ATX |
| Memory | 4 x DIMMs, max. 64GB, DDR4 2666/2400/2133 MHz,ECC and non-ECC, un-buffered memory |
| Expansion Slots | "1 x PCI Express 3.0/2.0 x16 slot(max.@x16 mode) |
| " | 2 x PCI Express 2.0 x1 slots |
| Storage | - 6 x Serial ATA 6.0 Gb/s connectors with RAID 0, RAID 1 and RAID 10 support | - 1 x M.2 socket 3 with M Key |
| LAN | Realtek 8111H Gigabit LAN Controller |
| Audio | Realtek ALC 887-VD2 8-Channel High Definition Audio CODEC |
| USB Ports | - 4 x USB 3.0 ports (4 ports at back panel) | - 2 x USB 3.0/2.0 ports ( 2 ports at mid-board) | - 4 x USB 2.0/1.1 ports ( 4 ports at mid-board) |
| ASUS Unique Features | ASUS 5X PROTECTION III | - ASUS SafeSlot Core: Fortified PCIe Slot prevents damage | - ASUS LANGuard: Protects against LAN surges, lightning strikes and static-electricity discharges! | - ASUS Overvoltage Protection: World-class circuit-protecting power design | - ASUS Stainless-Steel Back I/O: 3X corrosion-resistance for greater durability! | - ASUS DIGI+ VRM: 6 Phase digital power design | Superb performance | UEFI BIOS | - Most advanced options with fast response time | Easy PC DIY | Safe motherboard mounting | - Component-free areas to minimize damage risk | Q-Design | - ASUS Q-DIMM | - ASUS Q-Slot | UEFI BIOS EZ Mode | - featuring friendly graphics user interface | - ASUS CrashFree BIOS 3 | - ASUS EZ Flash 3 |
| Back Panel I/O Ports | 1 x PS/2 keyboard (purple) | 1 x PS/2 mouse port (green) | 1 x HDMI port | 1 x DVI-D port | 1 x D-Sub port | 1 x LAN (RJ-45) port | 2 x USB 3.1 ports | 4 x USB 3.0/2.0 ports | 3 x Audio jacks support 8-channel audio output |
| Internal I/O Connectors | 1 x USB 3.0 connector supports additional 2 USB 3.0 ports | 2 x USB 2.0/1.1 connectors support additional 4 USB 2.0/1.1 ports | 6 x SATA 6.0Gb/s connectors | 1 x M.2 Socket 3 for M Key, type 2242/2260/2280/22110 devices,(both SATA & PCIE mode) | 1 x COM connector | 1 x CPU Fan connector | 1 x Fan RGB header | 1 x Chassis Fan connector (Support DC & PWM mode) | 1 x Front panel audio connector | 1 x 24-pin EATX Power connector | 1 x 8-pin ATX 12V Power connector | 1 x 2-pin Clear CMOS | 1 x System Panel connector | 1 x Speaker connector | 1 x S/PDIF out header |
| BIOS | 128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI3.0, WfM2.0, SM BIOS 3.0, ACPI 6.1, Multi-language BIOS, ASUS EZ Flash 3, ASUS CrashFree BIOS 3, My Favorites, Last Modified log, F12 PrintScreen, ASUS DRAM SPD (Serial Presence Detect) memory information, F6 Qfan Control | Warranty Information |
| Warranty | Manufacturer's Warranty |
| Manufacturer's Site | No |
|---|---|
| Product Link | No |
