| SPECIFICATIONS | |
| Projection | Brightness: | 2500 ANSI Lumens (Max) | Contrast Ratio: | 2200:1 Typical (Full On/Full Off) | Resolution: | SVGA native resolution (800x600) | Uniformity: | 90% Typical (Japan Standard - JBMA) | Projection Lens: | F-Stop: F/ 2.41-2.55 | Focal length, f=21.8~24mm | Zoom Lens: Manual 1.1x | Throw ratio: 1.95 (wide) - 2.15 (tele) | Image Size: | 58.16 - 769.62 cm (22.9" - 303") (diagonal) | Projection Distance: | 3.28 ft ~ 39.37 ft (1m ~ 12m) |
| Lamp Information | Lamp Life Cycle: | Up to 3000-hour Typical | Up to 4000-hour Eco-Mode | Lamp Type: | Philips 185W user-replaceable |
| Video Compatibility | Composite Video / S-Video: NTSC (M, 3.58, 4.43), PAL (B, D, G, H, I, M, N, 4.43), SECAM (B, D, G, K, K1, L, 4.25/4.4) |
| Audio | Multimedia Audio:2W Speaker |
| Size & Weight | Dimensions (W x H x D): | 28.60 x 8.99 x 19.20 cm (11.26'' x 3.54'' x 7.56'') | Weight: | 5.3 lbs (2.4kg) |
| Electrical | Power: | Universal 90-264V AC 50Hz-60Hz | Power Consumption Operational: | Normal mode: 234W | Eco mode: 209W | Power saving mode: less than 14W (Fan speed at minimum) | Standby mode: less than 1W |
| Environmental | Operating temperature: | 5C - 35C (41F - 95F) | Humidity: | 80% (maximum) | Storage temperature: | 0C - 60C (32F - 140F) | Humidity: | 90% (maximum) |
| What's in the box | Power Cable | VGA Cable | CD Users Guide | Remote Control with 2 AAA Batteries | Quick Setup guide & Product Information guide |
| Connectivity | Power: One AC power socket (3-pins - C14 inlet) | VGA input: Two 15-pins D-sub connectors (Blue), VGA-A & VGA-B, for analog RGB/Component input signals. | VGA output: One 15-pins D-sub connector (Black)for VGA-A loop through. | S-Video input: One standard 4-pins min-DIN SVideo connector for Y/C signal. | Composite video input: One Yellow RCA jack for CVBS signal. | Analog Audio input: One 3.5mm stereo mini phone jack (Green). | Fix audio output: One 3.5mm stereo mini phone jack (Blue). | USB port: One USB slave for remote support. | USB port: One USB slave for remote support. | Warranty Information |
| Warranty | Dell 2 Year Next Business Day On Site Warranty |
