| SPECIFICATIONS | |
| Projection | Brightness: | 4100 ANSI Lumens9 (Max.) | Contrast Ratio: | 2000:1 Typical (Full On/Full Off) | Resolution: | XGA (1024 x 768) | Uniformity: | 80% Typical (Japan Standard - JBMA) | Projection Lens: | F-Stop: F/2.4~2.66 | Focal length, f = 18.2~21.8mm | Throw Ratio: | 1.6 (wide) -1.92 (tele) | Lens Offset: | 115 5% | Image Size: | At 3.94 ft (1.2m) distance, diagonal projection image size of 30.8" (0.78m). | At 32.81 ft (10m) distance, diagonal projection image size of 307" (7.8m). | Projection Distance: | 3.94 ft ~ 32.81 ft(1.2m ~ 10m) |
| Lamp Information | Lamp Life Cycle: | Up to 2,000 hours Typical | Up to 2,500 hours Eco-Mode | Lamp Type: | Philips 300W user-replaceable |
| Video Compatibility | Composite Video / S-Video input: NTSC [J, M, 4.43) PAL (B, D, G, H, I, M, N, Nc, 60) SECAM (B, D, G, K, K1, L) | Component Video via VGA input: 480i/p, 576i/p, 720p, 1080i | Component Video via HDMI input: 480i/p, 576i/p, 720p, 1080p |
| Audio | 2x 5W speaker RMS |
| Size & Weight | Dimensions (W x H x D): | 11.26" x 4.33" x 9.76" (286 x 110 x 247.8 mm) | Weight: | 6.4 lbs (2.9 kg) |
| Electrical | Power: | Universal AC 100-240 50-60Hz with PFC input | Power Consumption Operational: | Full Mode: 375W 10% @ 110Vac (network on) | Eco-Mode: 320W 10% @ 110Vac (network on) | Power-Saving Mode: 10W (wireless & network on) | Standby Mode: 0.5W (network, VGA Out, & wireless off) |
| Environmental | Operating temperature: | 5C ~ 35C (41F ~ 95F) | Humidity: | 80% Maximum | Storage temperature: | 0C ~ 60C (32F ~ 140F) | Humidity: | 90% Maximum | Shipping Temperature: | -20C - 60C (-4F - 140F) |
| What's in the box | Power Cable | VGA Cable | Carry Case | USB cable | CD Users Guide | Remote Control with 2 AAA Batteries | Quick Setup guide & Product Information guide |
| Connectivity | AC power input socket | 2x 15-pin D-Sub for analog RGB/component input signals | 1x 15-pin D-Sub for VGA-A loop through | 1x Composite Video RCA jack for CVBS signal | 1x 4-pin S-Video for Y/C signal | 1x mini USB-B slave for remote support and firmware update | 1x USB-A for USB Viewer | 1x USB-B for USB Display | USB Wi-Fi connector for optional wireless functionality (USB wireless dongle sold seperately) | 2x 3.5mm stereo mini phone jack and 1x pair of RCA connectors (left/right) for audio input | 1x 3.5mm stereo mini phone jack for audio output | 1x RJ45 connector for networking | 1x HDMI 1.3 (HDCP compliant) | 1x mini-DIN 6-pin RS232 port allows connection to a commercial RS232 control box for remote projector control | 1x DC jack 12V @200mA output, relay control for automatic projection screen control | Warranty Information |
| Warranty | Dell 2 Year Next Business Day On Site Warranty |
| Manufacturer's Site | Visit the manufacturer's website |
|---|---|
| Product Link | Visit the manufacturer's page for this product |
