| SPECIFICATIONS | |
| General | 802.11b/g/n standards | Wireless speed: up to 54 Mbps (802.11g), 300 Mbps (802.11n) | G.dmt: 8 Mbps downstream, 832 Kbps upstream | G.lite: 1.5 Mbps downstream, 512 Kbps upstream | ADSL2: 12 Mbps downstream, 1 Mbps upstream | ATM Forum UNI3.1/4.0 PVC (up to 8 PVCs) | Frequency range: 2.4 GHz to 2.4835 GHz, EIPR: 18.7dBm | Antennas: Dual 2x2 built-in MIMO antennas | ADSL2+: 24 Mbps downstream, 1 Mbps upstream | VC and LLC based multiplexing | PPP over Ethernet (PPPoE) | PPP over ATM (RFC 2364) | ITU-T I.610 OAM F4/F5 | ATM Adaptation Layer Type 5 (AAL5) | ATM QoS (Traffic Shaping) | Bridged or routed Ethernet encapsulation |
| Device Interfaces | RJ-11 ADSL port | 4x RJ-45 10/100BASE-TX Ethernet ports with auto MDI/MDIX | Factory reset button | Built-in 802.11n wireless LAN | WPS button | Wireless on/off switch (optional) | Power on/off switch |
| ADSL Standards | Multi-mode | ANSI T1.413 Issue 2 | ITU G.992.1 (G.dmt) Annex A | ITU G.992.2 (G.lite) Annex A | TU G.994.1 (G.hs) |
| ADSL2 Standards | ITU G.992.3 (G.dmt.bis) | Annex A/L/M, ITU G.992.4 (G.lite.bis) Annex A |
| Router Features | WAN/LAN Switchable Port (optional) | NAT & NAPT | DHCP server/client/relay | Static Routing, RIP v.1, v.2 | Universal Plug and Play (UPnP) compliant | Dynamic Domain Name System (DDNS) | Virtual server | SNTP, DNS proxy and IGMP proxy | Built-in NAT firewall | Stateful Packet Inspection (SPI) | DoS attacks prevention |
| Security | IGMP | PVC/VLAN port mapping (bridge mode) 64/128 bits | WEP data encryption | WPA/WPA2 (Wi-Fi Protected Access) security | MAC address-based access control | WPS | Packet filtering (IP/ICMP/TCP/UDP) | Supports IPv6 | Supports IPv6 | Warranty Information |
| Warranty | 12 Month Warranty |
