Play 3D games, watch Blu-ray 3D videos, and edit 3D photos on your 3D Monitors, TV, or projector. |  |
 |
Increase our gaming performance up to 2x with AMD CrossFire™ technology, 2.75x for TriFire configurations, or 3.75x with QuadFire configs. |
|  |
 |
|
|  |
 |
|
|  |
 |
|
|  |
 |
|
|  |
 |
|
| SPECIFICATIONS | |
| Graphics Engine | RADEON R9 380X |
| Video Memory | 4GB GDDR5 |
| Engine Clock | 1020MHz |
| Memory Clock | 1475MHz (5.9Gbps) |
| Memory Interface | 256bit |
| DirectX Support | 12 |
| Bus Standard | PCIE 3.0 |
| Standard Display Connecors | DL DVI-I/ DL DVI-D/ HDMI/ DisplayPort | Feature Support |
| OpenGL | Support |
| CrossFireX Technology | Support |
| ATI Stream Technology | Support |
| ATI Eyefinity Technology | Support |
| ATI Hypermemory Technology | N/A | Display Support |
| VGA Output | N/A |
| DVI Output | DL DVI-I/ DL DVI-D |
| DisplayPort | DisplayPort |
| HDMI | HDMI |
| TV Output | N/A |
| HDTV Output | N/A |
| HDCP Support | Support | Maximum Resolution |
| VGA | N/A |
| DVI | 2560x1600 |
| DisplayPort | 4096x2160 |
| HDMI | 4096x2160 | Power Specs + Board Dimensions |
| Board Dimensions | 266.65mmx111.2mmx38mm |
| Minimum System Power requirement (W) | 500W |
| Extension Power Connector | Two 6-Pin PCI Express Power Connectors | Features |
| GCN Architecture | A new design for AMD’s unified graphics processing and compute cores that allows them to achieve higher utilization for improved performance and efficiency. |
| AMD Eyefinty Technology | Run multiple displays from a single graphics board and expand your gaming field of view across all displays. |
| AMD App Acceleration | AMD App Accelerator creates a “co-processing” environment in which the compute processing potential in your AMD Radeon Graphics processor works together with the system central processor, to accelerate enabled applications. |
| AMD HD3D Technology | Supports the latest stereoscopic 3D content and display technologies | Play 3D games, watch Blu-ray 3D videos, and edit 3D photos on your 3D Monitors, TV, or projector. |
| Enhanced Anisotropic Filtering | Improved anisotropic filtering algorithm eliminates distracting artifacts and produces reference-level image quality. |
| Dolby TrueHD and DTS-HD Master Audio | Support of content protected, high bandwidth, 7.1 channels of surround sound over HDMDI and DisplayPort. |
| AMD HD Media Accelerator | Assumes rendering responsibility for HD encode (VCE)/decode (MPEG-4 ASP, H.264. MVC, MPEG2, etc.) and conclusively enable superior video playback quality with advanced hardware post-processing algorithms. |
| AMD PowerPlay Technology | AMD PowerPlay Technology dynamically adjusts clockspeeds in response to GPU load, saving power for just when you need it. |
| AMD PowerTune Technology | Maximizes performance under load conditions by dynamically increasing the GPU engine clock to take advantage of unused TDP headroom. Also allows users to configure their own TDP limit, within a provided range, for even higher performance or more power efficiency. |
| PCI Express 3.0 | Delivers double the bandwidth per lane of PCIe Gen 2 for faster GPU. |
| Advanced GDDR5 Memory Technology | GDDR5 memory provides the highest available memory bandwidth of any memory technology today, enabling higher GPU performance. |
| PCS-Professional Cooling System | The unique cooling technology can decrease operating environment temp. Effectively, and enhance headroom for OC capabilities. |
| Gold PowerKIT | The Solidly-built Components enhance the stability, performance, efficiency and quality. |
| HDMI | Integrated high speed HDMI output with 1080p 120Hz 3D Stereoscopic support, and 4K resolution display support. |
| Enhanced Internet Applications | Accelerate rendering performance with the latest web browsers and programming interfaces. |
| Microsoft DirextX 12 | Get intense gaming performance and unrivalled image quality with stunning 3D visual effects, realistic lighting and lifelike imagery. |
| UEFI Support | Better security by helping protect the pre-startup—or pre-boot—process against bootkit attacks and faster startup times and resuming from hibernation. |
| Virtual Super Resolution | Get quality that rivals 4K, even on a 1080p display while playing your favorite online games thanks to AMD's VSR. |
| FREESYNC TECHNOLOGY | AMD FreeSync technology puts an end to choppy gameplay and broken frames with fluid, artifact-free performance at virtually any framerate. |
| LIQUIDVR TECHNOLOGY | Enabling liquid-smooth visuals and high frame rates with AMD LiquidVR technology, which will provide broad compatibility, plug-and-play ease of use, and stable platform support for tomorrow's VR vendors and technologies. |
| TRUE AUDIO TECHNOLOGY | True to life echoes, convolution reverbs and fuller sounding environments with increased voices and audio objects deliver a richer and more immersive gaming soundscape. | Warranty Information |
| Warranty | 2 Year Warranty |
| Manufacturer's Site | Visit the manufacturer's website |
|---|---|
| Product Link | Visit the manufacturer's page for this product |
- Max IT ALL - Big G, 5 April 2016
Well lets not babble here. This card is great. I can't say one thing bad about it. Maxed out Black Ops 3 1080p didn't get anything under 75 fps. Maxed out battlefield 4 1080p didn't get anything under 75/80 fps. What ever I throw at it... It man handles it. This card replace my PowerColor Hd 6950 2GB. I couldn't be happier. Very under rated brand... My last card lasted me close to 4 years and is still running strong.Rig card installed into :
BASE HARDWARE
---------------------------
CPU: Amd Fx 8350 Vishera Black Edition. Stock Clock 4ghz
RAM: 16GB DDR 3 1600Mhz
PSU: RAID MAX 730 Watt Modular
MB: ASUS M5A97 LE R2.0 AMD 970/SB950 Socket AM3+
- What an upgrade - Rod, 13 December 2015
I upgraded from an ATi 5870 (made when ATi wasn't owned by AMD). That card was awesome and provided me with good grunt until of late. I then switched to a 2560x1080 ultrawide monitor and noticed that I needed more grunt. Step in, the R9 380x. Wow, what a leap. My games don't seem to have any 'slow-downs' and I can play all my games on (that I've tested so far) max/highest settings at 2560x1080. Powercolor have really done well with this card in terms of specs and actual performance. It looks great as well. A little noisy when pushed really hard but noise doesn't concern me - I'm after performance and low temperatures - I will worry about noise when I'm a lot older. In any case, my ATi 5870 was louder when pushed so this is not so bad.
At idle, this card hovers between 32-39 deg C dependent on ambient temperature. On a really warm day, 31 deg C ambient, I hit a max temp of 71 deg C at full load and 39 deg C idle. I've got two inlet and two exhaust fans so some users may hit 80 deg C whilst gaming, if case ventilation is poor...but I think Powercolor have done such a good job that this card will take a lot of punishment.
The day of typing this review was cold and wet so max temp whilst gaming was 60 degrees. Rome Total War II in full 2560x1080 glory is a sight indeed. I understand that AMD Crimson is still in it's infancy and this card will just get better and better with each driver release. One other thing I notice after a gaming session is how fast the card cools back down to idle temperatures - less than 60 seconds! This might be due to the large dual fan setup of the card and massive heat-sink. Anyway, my rig is perfect now - I'm looking forward to gaming over Christmas. Guys, if you are thinking of getting this - don't hesitate if you need an upgrade now. I was thinking about 4GB Nvidia 960 which was cheaper but this has just that little bit of extra grunt that will keep me happy for another 4/5 years. I've got a kid starting school and bills to pay so like most of you out there, I can't upgrade frequently.
Oh, and don't let the scaremongers out there fool you into thinking you need a massive PSU for AMD cards. I've got an ageing 650 watt PSU and its holding up fine. It's probably delivering around 450 watts but total system draw should be under 300 watts. I don't have anything to measure accurately but please read some tech reviews - there are a few with power draw specs and comparisons. I chose this over other brands because of price - I'm not ashamed to admit. This was the cheapest R9 380x out there but not the slowest by any means. 1020MHz core - 1475 MHz RAM speed.
I will happily give this 5 stars - ratings are relative to the experience of the users that rate them and whether the product ticked the boxes they were after. I was looking for more power, more RAM, good price, some gaming longevity and lower temperatures - this ticked all of my boxes so 5 out of 5 for me and bonus: This card not only looks great but has outstanding build quality and a back-plate. And Wootware were awesome - thank you. - Great 1080p performance - Michael, 12 December 2015
I've been playing MGSV:TPP, Star Wars Battlefront and Dragon Age: Inquisition non stop after receiving the card a few days ago. Each title maxed out on ultra detail, 1080p on an i7 3770 with 16GB RAM. Sure there have been times with <40 fps but most of the time I'm averaging out at 55fps. I've also played some less demanding titles like LoL and Brutal Doom and it's an absolute treat with VSR enabled..
