| SPECIFICATIONS | |
| Brand | Asus |
| Series | 4G Modem Router |
| Model | 4G-AC68U |
| Network Standard | IEEE 802.11a, b, g, n, ac, ax, IPv4, IPv6 |
| Product Segment | AC1900 Ultimate AC Performance (600 1300 Mbps) |
| Coverage | Large Homes |
| Data Rate | 802.11a: 6,9,12,18,24,36,48,54 Mbps |
| 802.11b: 1, 2, 5.5, 11 Mbps | |
| 802.11g: 6,9,12,18,24,36,48,54 Mbps | |
| 802.11n: up to 450 Mbps | |
| 802.11n TurboQAM: up to 600 Mbps | |
| 802.11ac: Up to 1300 Mbps | |
| Connectivity Technology | LTE: Downlink 300 Mbps / Uplink 50 Mbps |
| HSPA : Downlink 42.2 Mbps / Uplink 5.76 Mbps | |
| 4G FDD-LTE: 800 /1800 /2100 /2600 | |
| 4G TDD-LTE: 2600 | |
| 3G UMTS: 900 /2100 | |
| Antenna | 2x External antenna |
| 1x Internal 2dBi antenna for Wi-Fi | |
| 2x Detachable 3dBi antenna for Mobile | |
| Transmit/Receive | MIMO Technology |
| 2.4 GHz 3 x 3 | |
| 5 GHz 3 x 3 | |
| Memory | 128 MB Flash |
| 256 MB RAM | |
| Operating Frequency | 2.4 GHz |
| 5 GHz | |
| Encryption | 64-bit WEP, 128-bit WEP, WPA2-PSK, WPA-PSK, WPA-Enterprise , WPA2-Enterprise , WPS support |
| Firewall & Access Control | Firewall: SPI Intrusion Detection, DoS Protection |
| Access Control: Parental Control, Network Service Filter, URL Filter, Port Filter | |
| Management | UPnP, IGMP v1/v2/v3, DNS Proxy, DHCP, NTP Client, DDNS, Port Trigger, Universal Repeater, System Event Log |
| VPN Support | IPSec Pass-Through |
| PPTP Pass-Through | |
| L2TP Pass-Through | |
| PPTP Server | |
| OpenVPN Server | |
| PPTP Client | |
| L2TP Client | |
| OpenVPN Client | |
| WAN Connection Type | Internet Connection Type : Automatic IP, Static IP, PPPoE(MPPE supported), PPTP, L2TP |
| Multicast Proxy Support | |
| Multicast Rate Setting Support | |
| Ports | RJ45 for 10/100/1000/Gigabits BaseT for LAN x 4, RJ45 for 10/100/1000/Gigabits BaseT for WAN x 1 |
| 1x USB 3.0 | |
| 1x SIM Card | |
| Button | WPS Button, Reset Button, Power Button, Wireless on/off Button |
| LED Indicators | Power x 1 |
| WAN x 1 | |
| Wi-Fi x 2 | |
| LAN x 1 | |
| USB x 1 | |
| WPS x 1 | |
| 3G/4G signal x 4 | |
| Power Supply | AC Input: 110V - 240V(50 - 60Hz) |
| DC Output: 19 V with max. 2.37 A current | |
| Dimensions | 247mm x 76mm x 168mm |
| Weight | 795g |
| Colour | Black |
| Warranty Information | |
| Warranty | 3 Year Warranty |
| Manufacturer's Site | Visit the manufacturer's website |
|---|---|
| Product Link | Visit the manufacturer's page for this product |
