| SPECIFICATIONS | |
| Brand | ASUS |
| Model | 970 PRO GAMING/AURA |
| Series | 970 AM3+ |
| CPU | Build in AMD AM3+ FX/Phenom II/Athlon II/Sempron 100 Series Processors | Supports AM3+ 32 nm CPU | Supports CPU up to 125 W | AMD Cool 'n' Quiet Technology |
| Chipset | Build in AMD 970/SB950 |
| Memory | 4 x DIMM, Max. 32GB, DDR3 2133(O.C.)/1866/1600/1333/1066 MHz Non-ECC, Un-buffered Memory * | Dual Channel Memory Architecture | * Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists). | * Due to OS limitation, when installing total memory of 4GB capacity or more, Windows 32-bit operation system may only recognize less than 3GB. Install a 64-bit Windows OS when you want to install 4GB or more memory on the motherboard. | * Due to CPU spec., AMD 100 series CPUs support up to DDR3 1066MHz. With ASUS design, this motherboard can support up to DDR3 1333MHz. |
| System Bus | Up to 4.8 GT/s HyperTransport 3 |
| Multi-GPU Support | Supports NVIDIA Quad-GPU SLI Technology | Supports AMD Quad-GPU CrossFireX Technology |
| Expansion Slots | 2 x PCIe 2.0 x16 (x16 or dual x8) | 2 x PCIe 2.0 x1 | 2 x PCI |
| Storage | AMD SB950 controller : | 6 x SATA 6Gb/s port(s), black, | Support Raid 0, 1, 5, 10 | 1 x M.2 Socket 3, , with M Key, type 2242/2260/2280 storage devices support (PCIE 2.0 x4) |
| LAN | Intel I211-AT, 1 x Gigabit LAN Controller(s), GameFirst technology | Anti-surge LANGuard |
| Audio | SupremeFX 8-Channel High Definition Audio CODEC | - Supports : Jack-detection, Multi-streaming, Front Panel MIC Jack-retasking | - High quality 115 dB SNR stereo playback output | Audio Feature : | - SupremeFX Shielding Technology | - Optical S/PDIF out port(s) at back panel | - Sonic Radar II |
| USB Ports | ASMedia USB 3.1 controller : | 2 x USB 3.1 port(s) (2 at back panel, , Type-A) | ASMedia USB 3.0 controller : | 2 x USB 3.0 port(s) (2 at mid-board) | AMD SB950 controller : | 14 x USB 2.0 port(s) (8 at back panel, , 6 at mid-board) |
| Special Features | Gamer's Guardian: | - ESD Guards on LAN, Audio, KBMS and USB3.0/2.0 ports | - DRAM Overcurrent Protection | - Stainless Steel Back I/O | - DIGI+ VRM | ASUS Exclusive Features : | - AI Suite 3 | - Ai Charger+ | - USB 3.1 Boost | - Disk Unlocker | ASUS Quiet Thermal Solution : | - ASUS Fan Xpert 2 | ASUS EZ DIY : | - ASUS O.C. Tuner | - ASUS CrashFree BIOS 3 | - ASUS EZ Flash 2 | - ASUS UEFI BIOS EZ Mode | - Push Notice | ASUS Q-Design : | - ASUS Q-Shield | - ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED) | - ASUS Q-Slot | - ASUS Q-DIMM | Media Streamer | RAMCache | AURA: RGB Lighting Control |
| Operating System Support | Windows 10 , 64bit | Windows 8.1 , 64bit | Windows 7 , 32bit/64bit |
| Back I/O Ports | 1 x PS/2 keyboard/mouse combo port(s) | 1 x LAN (RJ45) port(s) | 2 x USB 3.1 (red)Type-A | 8 x USB 2.0 | 1 x Optical S/PDIF out | 6 x Audio jack(s) |
| Internal I/O Ports | 1 x ReTry jumper | 1 x Safe Boot jumper | 1 x USB 3.0 connector(s) support(s) additional 2 USB 3.0 port(s) (19-pin) | 3 x USB 2.0 connector(s) support(s) additional 6 USB 2.0 port(s) | 1 x M.2 Socket 3 for M Key, type 2242/2260/2280 devices | 1 x TPM header | 1 x COM port(s) connector(s) | 6 x SATA 6Gb/s connector(s) | 1 x CPU Fan connector(s) (1 x 4 -pin) | 1 x CPU OPT Fan connector(s) (1 x 4 -pin) | 3 x Chassis Fan connector(s) (3 x 4 -pin) | 1 x 24-pin EATX Power connector(s) | 1 x 8-pin ATX 12V Power connector(s) | 1 x Front panel audio connector(s) (AAFP) | 1 x System panel(s) | 1 x Clear CMOS jumper(s) | 1 x Water Pump header (4-pin) | 1 x Slow Mode jumper(s) |
| Accessories | User's manual | I/O Shield | 2 x SATA 6Gb/s cable(s) | 1 x M.2 Screw Package | 1 x pack of cable tie | 1 x Supporting DVD | 1 x SLI bridge(s) | 1 x 12 in 1 Cable Label (s) |
| Support Disc | Drivers | ASUS Utilities | EZ Update | Anti-virus software (OEM version) |
| Form Factor | ATX Form Factor | 12 inch x 9.6 inch ( 30.5 cm x 24.4 cm ) | Warranty Information |
| Warranty | 2 Year Warranty |
