| SPECIFICATIONS | |
| Brand | ASUS |
| Model | DSL-N66U |
| Series | Dual-Band Wireless-N900 ADSL/VDSL |
| Network Standard | IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IPv4, IPv6 |
| Product Segment | N900 ultimate performance; 450+450Mbps |
| Wi-Fi Data Rate | 802.11a : 6,9,12,18,24,36,48,54Mbps | 802.11b : 1, 2, 5.5, 11Mbps | 802.11g : 6,9,12,18,24,36,48,54Mbps | 802.11n : up to 450Mbps |
| xDSL Data Rate | VDSL2/ADSL2+/ADSL2/ADSL multimode | Up to 100Mbps/100Mbps upstream/downstream | Support Annex A/B/I/J/L/M | Support all VDSL2 profiles -8a, 8b, 8c, 8d, 12a, 12b, 17a and 30a | VDSL2 interface compliance with ITU-T993.2 | G.992.1 (G.dmt), Annex A, and B Compliant | G.992.2 (G.lite), Annex A, and B Compliant | ANSI T1.413 Compliant | G.992.3 (ADSL2) Compliant, Annex A, B, L, and M | G.992.5 (ADSL2+) Compliant, Supporting Annex A, B, and M | G.993.2 Compliant, Annex A, B, up to profile 30a with external AFE. | ATM and PTM (dual-priority) |
| Antenna | Internal 2 dBi antenna x 3 |
| LED Indicator | Power, Internet, LAN x 1, xDSL, 2.4 GHz Wi-Fi, 5 GHz Wi-Fi, USB x 1 |
| Button | WPS Button, Reset Button, Power Switch, Wireless on/off Button |
| Ports | 4 x RJ45 10/100/Gigabits BaseT for LAN | 1 x RJ45 10/100/Gigabits BaseT for WAN | 1 x RJ11 for xDSL |
| USB Ports | USB 2.0 x 2 |
| Router Special Features | AiCloud, Printer server, Download Master, AiDisK, Multiple SSIDs, Parental Control |
| Operating Frequency | 2.4GHz | 5GHz |
| Operation Channel | 13 Europe (ETSI) |
| Memory | 16MB Flash/64MB DDR2 RAM for Modem/Router | 64MB DDR2 RAM for Wi-Fi |
| Receive Sensitivity | 11b: -89dBm @ 11Mbps and PER<8%) | 11g: -75dBm @ 54Mbps and PER<10%) | 11a: -74dBm @ 54Mbps and PER<10%) |
| Security | 64-bit WEP, 128-bit WEP, WPA2-PSK, WPA-PSK, WPA-Enterprise , WPA2-Enterprise , Radius with 802.1x, WPS support |
| Management | Web-based GUI configuration | Firmware upgraded, configuration data uploaded and downloaded via Web-based GUI | Auto VPI/VCI detection | Configuration backup and restore | Diagnostics | Log & Trace function |
| Utilities | Download master | support BT, NZB, HTTP, ED2K | support encryption, DHT, PEX and magnet link | upload and download bandwidth control | download scheduling | ?Media server | ?File server: Samba and FTP server with account management | ?PPTP VPN server | ?Network map | ?Traffic monitor |
| VPN Support | IPSec Pass-Throuth | PPTP Pass-Through | L2TP Pass-Through | PPTP server |
| Power Adapter | AC Input : 100 ~240 V(50~60HZ) | DC Output : 19 V/3.42 A |
| Certificates | CE, C-Tick, Telepermit |
| Dimensions | 6.5 x 15.5 x 25 cm (WxDxH) |
| Weight | 820 g (Device Only) |
| OS Support | Windows 8 , 32bit/64bit | Windows 7 , 32bit/64bit | Windows Vista , 32bit/64bit | Windows XP , 32bit/64bit | Mac OS X | Linux | Warranty Information |
| Warranty | 3 Year Warranty |
| Manufacturer's Site | Visit the manufacturer's website |
|---|---|
| Product Link | Visit the manufacturer's page for this product |
