| SPECIFICATIONS |
| Brand | ASUS |
| Series | ExpertWiFi |
| Model | ExpertWiFi EBR63 |
| Network Standard | IEEE 802.11a |
| IEEE 802.11b |
| IEEE 802.11g |
| WiFi 4 (802.11n) |
| WiFi 5 (802.11ac) |
| WiFi 6 (802.11ax) |
| IPv4 |
| IPv6 |
| Product Segment | AX3000 ultimate AX performance : 2402 Mbps+ 574 Mbps |
| Data Rate | 802.11a : up to 54 Mbps |
| 802.11b : up to 11 Mbps |
| 802.11g : up to 54 Mbps |
| WiFi 4 (802.11n) : up to 300 Mbps |
| WiFi 5 (802.11ac) : up to 1734 Mbps |
| WiFi 6 (802.11ax) (2.4GHz) : up to 574 Mbps |
| WiFi 6 (802.11ax) (5GHz) : up to 2402 Mbps |
| Antenna | 4 External Antenna |
| Transmit / Receive | 2.4GHz 2x2 |
| 5GHz 2x2 |
| Processor | 1.7GHz quad-core processor |
| Memory | 256MB FLASH |
| 512MB RAM |
| Boosts Speed | OFDMA (Orthogonal Frequency Division Multiple Access) |
| Beamforming: standard-based and universal |
| 1024-QAM high data rate |
| 20/40/80/160 MHz bandwidth |
| Operating Frequency | 2.4 GHz |
| 5 GHz |
| Operating Mode | Wireless Router Mode |
| AiMesh Node Mode |
| Access Point Mode |
| I/O Ports | 1x RJ45 for Gigabits BaseT for WAN |
| 4x RJ45 for Gigabits BaseT for LAN |
| 1x USB 3.2 Gen 1 Type-A |
| 1x USB 2.0 Type-A |
| Buttons | WPS Button, Reset Button, Power Switch |
| LED Indicator | POWER, WAN, LAN, 5G, 2.4G |
| Power Supply | AC Input : 110V~240V(50~60Hz) |
| DC Output : 12V with max. 2A current |
| Mounting | Wall Mount |
| Product Dimentions | 225mm * 127mm * 146mm |
| AiMesh | AiMesh |
| - Primary AiMesh Router |
| - AiMesh Node |
| Device Access Control | Allow you to block access to unwanted websites and apps |
| Web & Apps Filters |
| Time Scheduling |
| Safe Browsing |
| Customized Internet Schedule |
| - Maximum Device Access Control Profile :12 |
| - Maximum Device Access Control Content Filter Rule :12 |
| Dashboard | Dashboard |
| Self-Defined Network | Self-Defined Network Type |
| - Employee |
| - Guest Portal |
| - Guest Network |
| - Scheduled Network |
| - IoT Network |
| - VPN Network |
| - Maximum Self-Defined Network Rule :16 |
| Multiple Network |
| VLAN |
| Captive Portal for Free WiFi |
| VPN WiFi |
| WiFi Scheduling: One Time Access |
| WiFi Scheduling: Weekly Schedule |
| WiFi share: QR code, PDF file |
| Bandwidth Limiter |
| AP isolate |
| DNS Server Connection |
| Security | AiProtection |
| VPN |
| WPS |
| Let's Encrypt |
| DNS-over-TLS |
| SSH |
| Firewall |
| - Maximum Firewall Keyword Filter :64 |
| - Maximum Firewall Network Service Filter :32 |
| - Maximum Firewall URL Filter : 64 |
| AiProtection | AiProtection Pro |
| - Router Security Assessment |
| - Malicious Site Blocking |
| - Two-Way IPS |
| - Infected Device Prevention and Blocking |
| VPN | VPN Client L2PT |
| VPN Client Open VPN |
| VPN Client PPTP |
| VPN Client WireGuard |
| VPN Server IPSec |
| VPN Server Open VPN |
| VPN Server PPTP |
| VPN Server WireGuard |
| VPN Fusion |
| Support Surfshark |
| Traffic Control | Adaptive QoS |
| - Bandwidth Monitor |
| - Bandwidth Limiter |
| - Real-time Traffic Monitor |
| - Wired Traffic Monitor |
| - Wireless Traffic Monitor |
| Traffic Analyzer |
| - Website History |
| WAN | - PPPoE |
| - PPTP |
| - L2TP |
| - IPSec |
| Dual WAN |
| 3G / 4G LTE Dongle |
| 4G / 5G Auto Mobile Tethering |
| Port Forwarding |
| Port Triggering |
| DMZ |
| DDNS |
| NAT Passthrough |
| - PPTP Pass-Through |
| - L2TP Pass-Through |
| - IPSec Pass-Through |
| LAN | DHCP Server |
| IGMP Snooping |
| IPTV |
| VLAN |
| Wireless | MU-MIMO |
| UTF-8 SSID |
| WiFi MAC Address Filter |
| - Maximum MAC Filters : 64 |
| Wireless Scheduler |
| USB application | 4G / 5G Auto Mobile Tethering |
| Media Server |
| Samba Server |
| FTP Server |
| Shared Folder Privileges |
| User Interface | WEB: ASUSWRT |
| APP: ASUS ExpertWiFi APP |
| Administration | Configuration Backup and Restore |
| Diagnosis Tools |
| Feedback System |
| System Log |
| New Device Connect Notification |
| Login Captcha |
| Connection Diagnosis |
| Auto Firmware Update |
| Warranty Information |
| Warranty | 3 Year Warranty |
