| SPECIFICATIONS | |
| Brand | ASUS |
| Series | DUAL Series |
| Model | Radeon RX 560 DUAL 4G (DUAL-RX560-4G / 90YV0HG0-M0NA00) |
| Chipset | |
| GPU | Radeon RX 560 |
| Chipset Manufacturer | AMD |
| Interface | PCIe 3.0 x16 |
| Base Clock | 1175Mhz |
| Boost Clock | Up to 1199MHz |
| Stream Processors | 1024 Shaders |
| Texture Units | 64 |
| GPU Architecture | AMD GCN 4.0 Architecture |
| Memory | |
| Infinity Cache | N/A |
| Effective Memory Clock | 6.8Gbps |
| Memory Size | 4GB |
| Memory Interface | 128-bit |
| Memory Type | GDDR5 |
| Memory Bandwidth | 112GB/s |
| 3D API | |
| DirectX | 12.0 |
| OpenGL | 4.6 |
| OpenCL | 2.1 |
| Vulkan | 1.3 |
| Shader Model | Shader Model 6.7 |
| Connectivity | |
| Ports | 2x DisplayPort 1.4 (with DSC) |
| 1x HDMI 2.0 (2.0 VRR and FRL) | |
| HDMI 4K Support | Yes |
| HDCP Support | HDCP 2.2 |
| General | |
| Features | ASUS DirectCU II with Dual Wing-Blade Fan Design |
| ASUS GPU Tweak Utility | |
| Zero RPM Fan Mode | |
| PCI Express 3.0 Support | |
| AMD FreeSync Technology | |
| DisplayPort 1.4 with DSC | |
| HDMI 2.0 VRR | |
| HDMI 4K Support | |
| 4K H264 Decode | |
| H265/HEVC Decode | |
| Game Driver Optimizations | |
| AMD Radeon VR Ready Premium | |
| AMD FidelityFX Super Resolution | |
| AMD Radeon Image Sharpening | |
| AMD Radeon Anti-Lag | |
| AMD Radeon Software | |
| Power Requirements | |
| Total Design Power (TDP) | 75W |
| Recommended Power Supply | 450W |
| Power Connector | 1x 8-Pin PEG Connector |
| Physical Aspects | |
| Form Factor | ATX |
| Slot Width | Dual Slot |
| Dimensions | 242 x 128 x 40mm (L x W x H) |
| Warranty Information | |
| Warranty | 3 Year Warranty |
| Manufacturer's Site | Visit the manufacturer's website |
|---|---|
| Product Link | Visit the manufacturer's page for this product |
