| SPECIFICATIONS | |
| Brand | Biostar |
| Series | Pro |
| Model | TB250- BTC Ver. 6.x |
| Chipset | Intel B250 |
| CPU Support | Intel Core i3 LGA 1151 Processor | Intel Pentium LGA 1151 Processor | Intel Celeron LGA 1151 Processor | Maximum CPU TDP (Thermal Design Power): 95Watt |
| Memory | Support Dual Channel DDR4 2400 / 2133 / 1866 MHz | 2x DDR4 DIMM Memory Slot | Supports up to 32GB Memory Maximum | *DDR4 2400 for 7th Generation Intel Core Processor Family |
| Expansion Slot | 1x PCI-E x16 3.0 Slot | 5x PCI-E x1 3.0 Slot (using for bitcoin mining, it is suggested to change to PCI-E 1.0 via BIOS) |
| Storage | 6x SATA3 Connector | 1x M.2 Key M 32Gb/s Connector, support M.2 type 2242 / 2260 / 2280 SATA 6Gb/s & PCIe Storage |
| USB | 4x USB 3.0 Port | 1x USB 3.0 Header | 2x USB 2.0 Port | 2x USB 2.0 Port (only 5V power, up to 1.5A) | 2x USB 2.0 Header |
| LAN | Realtek RTL8111H - 10/100/1000 Controller | Support Super LAN Surge Protection |
| Integrated Video | By CPU model | Supports DX12 | Supports HDCP |
| Codec | Realtek ALC887 8-Channel HD Audio | Support HD Audio |
| Rear I/O | 1x PS/2 Mouse | 1x PS/2 Keyboard | 4x USB 3.0 Port | 2x USB 2.0 Port | 2x USB 2.0 Port(only 5V power, up to 1.5A) | 1x DVI-D Connector, resolution up to 1920 x 1200 @60Hz | 1x RJ-45 Port | 3x Audio Connector |
| Internal I/O | 1x USB 3.0 Header | 2x USB 2.0 Header | 6x SATA3 6Gb/s Connector | 1x SATA Power Connector (for rear USB power enhancement) | 1x M.2 Key M 32Gb/s Connector, support M.2 type 2242 / 2260 / 2280 SATA 6Gb/s & PCIe Storage | 1x Front Audio Header | 1x Front Panel Header | 1x CPU Fan Header | 2x System Fan Header | 1x Serial Header | 2x PCI-E 12V 4Pin Connector (Must be installed when using for bitcoin mining.) |
| H/W Monitoring | CPU / System Temperature Monitoring | CPU / System Fan Monitoring | Smart / Manual CPU Fan Control | System Voltage Monitoring |
| Dimension | ATX Form Factor | 295 x 210 mm |
| OS Support | Support Windows 10 (x64) for Intel 7th Generation Processor | Support Windows 7 / 8.1 (x64) / 10 (x64) for Intel 6th Generation Processor |
| Bundled Software | BullGuard | Smart Speed LAN (Windows 7 / 8.1 only) | Intel Rapid Storage Technology |
| Accessories | 2x SATA Cable | 1x I/O Shield | 1x DVD Driver | 1x User Manual |
| Features | Supports 100% Solid Capacitor | Supports Charger Booster | Supports BIOS Online Update | Warranty Information |
| Warranty | 3 Year Warranty |
| Manufacturer's Site | Visit the manufacturer's website |
|---|---|
| Product Link | Visit the manufacturer's page for this product |
