| SPECIFICATIONS | |
| Brand | Cooler Master |
| Series | MasterAir Series |
| Model | MasterAir MA824 Stealth Black (MAM-D8PN-318PK-R1) |
| Materials | Copper |
| Aluminium | |
| Stainless steel | |
| Plastic | |
| Cooler | |
| Heatpipe Design | 8x heatpipes with dense aluminium fins |
| Intel Socket Support | LGA1700, LGA1200, LGA115x |
| AMD Socket Support | AM5, AM4 |
| Case Clearance | 165.6mm |
| RAM Clearance | 42mm with dual fans |
| 67mm with single fan | |
| Fans | |
| Fan Dimensions | Mobius 120: 120 x 120 x 25mm (L x W x D) |
| Mobius 135: 135 x 135 x 25mm (L x W x D) | |
| Fan Speed | Mobius 120: 0 - 1950 RPM ±5% |
| Mobius 135: 0 - 1550 RPM ±5% | |
| Fan Airflow | Mobius 120: Up to 63.1 CFM |
| Mobius 135: Up to 63.6 CFM | |
| Fan Air Pressure | Mobius 120: Up to 2.69 mmH20 |
| Mobius 135: Up to 1.92 mmH20 | |
| Fan Noise | Mobius 120: Up to 22.6dBA |
| Mobius 135: Up to 24.6dBA | |
| Fan Connector | 4-pin PWM |
| Bearing Type | Loop Dynamic Bearing |
| Fan Rated Voltage | 12VDC |
| Fan Rated Current | 0.1A for Mobius 135, 0.12A for Mobius 120 |
| Fan Power Consumption | 2.4 to 3.0W approx (maximum) |
| General | |
| Colour | All Black |
| Dimensions | 162.2× 150.6 × 165.6mm (L x W x H) |
| Weight | 1.63kg |
| Warranty Information | |
| Warranty | 5 Year Warranty |
| Manufacturer's Site | Visit the manufacturer's website |
|---|---|
| Product Link | Visit the manufacturer's page for this product |
- Master-fully FAN-tastic! - DJDeon0, 10 April 2024
Yes - this is finally a CPU cooler that competes properly with Noctua's NH-D15.
Mine's block's plastic cover was damaged probably in shipping but luckily I ordered some extra thermal paste along with it - NOTE: it comes pre-applied with thermal paste - and there's no extra tube incase of the cover breaking off!!
I've replaced the standard Mobius 120 with a Mobius 120 OC and thus it keeps my i9-13900K perfectly stable under normal workstation loads (34'C -70'C in hot Durban climate under normal 'real-world' loads up to around 190W) - it does still thermal throttle the P-Cores like all 13900K's do but I'm really happy with this air cooler. It' HUGE and very heavy but it fits perfectly on my ASUS ROG STRIX WIFI-D4 board within my vintage Thermaltake A60 Armor case (any sleeper builders out here?!)
Super easy to install too.
Take caution when transporting your case - you don't want bent CPU pins!
Thanks again Wootware for you excellent service!
