| SPECIFICATIONS | |
| Brand | Cooler Master |
| Series | ELITE NEX PN500 |
| Model | MPW-5001-ACBK-PEU |
| Maximum Power | 400W |
| 500W Peak (for 20s) | |
| Colour | Black |
| Fan | 120mm Sleeve Fan Bearing |
| Efficiency | ≥ 75% @ Typical Load |
| Modular Design | Non-Modular |
| Connectors | |
| 24 Pin ATX | 1x ATX 24-Pin Connector |
| EPS (CPU) | 1x EPS 4+4 Pin Connector |
| PCIe | 1x PCIe 6+2-pin Connector |
| SATA & Four-Pin Peripheral | 6x SATA & 4-Pin Peripheral Connectors |
| Cable Length | |
| ATX Cable | 1x 550mm |
| EPS Cable | 1x 550mm |
| PCIe Cable | 1x 500mm |
| SATA Cable | 2x 400mm(SATA) +150mm(SATA)+150mm(Peripheral) |
| Input | |
| Input Voltage | 200 - 240V |
| AC Input | 3A |
| Input Frequency Range | 47Hz - 63Hz |
| Output | |
| Rail | +3.3V, +5V, +12V, -12V, +5Vsb |
| Max Output | 17A, 15A, 30A, 0.3A, 2.5A |
| General | |
| MTBF | >100,000 Hours |
| Safety Certifications | OVP / OPP / SCP / UVP / OTP / Inrush Protection |
| Regulatory Certifications | TUV,CE,CCC,EAC,UKCA |
| Dimensions | 245mm x 190mm x 95mm |
| Weight | 1.71Kg |
| Warranty Information | |
| Warranty | 3 Year Warranty |
| Manufacturer's Site | Visit the manufacturer's website |
|---|---|
| Product Link | Visit the manufacturer's page for this product |
