| SPECIFICATIONS | |
| Brand | DJI |
| Series | MAVIC |
| Model | MINI 2 |
| Aircraft | |
| Takeoff Weight | < 249g |
| Dimensions | Folded: 138mm x 81mm x 58mm |
| Unfolded: 159mm x 203mm x 56mm | |
| Unfolded (with propellers): 245mm x 289mm x 56mm | |
| Diagonal Distance | 213 mm |
| Max Ascent Speed | 5 m/s (S Mode) |
| 3 m/s (N Mode) | |
| 2 m/s (C Mode) | |
| Max Descent Speed | 3.5 m/s (S Mode) |
| 3 m/s (N Mode) | |
| 1.5 m/s (C Mode) | |
| Max Speed (near sea level, no wind) | 16 m/s (S Mode) |
| 10 m/s (N Mode) | |
| 6 m/s (C Mode) | |
| Max Service Ceiling Above Sea Level | 4000 m |
| Max Flight Time | 31 mins |
| Max Wind Speed Resistance | 8.5-10.5 m/s (Scale 5) |
| Max Tilt Angle | 40° (S Mode) |
| 25° (N Mode)* | |
| 25° (C Mode)* | |
| * Up to 40° under strong winds | |
| Max Angular Velocity (by default)* | 130°/s (S Mode) |
| 60°/s (N Mode) | |
| 30°/s (C Mode) | |
| * Can be adjusted to 250°/s with the DJI Fly app | |
| Operating Temperature | 0° to 40°C |
| Operating Frequency | 2.400-2.4835 GHz, 5.725-5.850 GHz |
| Transmitter Power | 2.400-2.4835 GHz |
| FCC ≤ 26 dBm | |
| CE ≤ 20 dBm | |
| SRRC ≤ 20 dBm | |
| 5.725-5.850 GHz | |
| FCC ≤ 26 dBm | |
| CE ≤ 14 dBm | |
| SRRC ≤ 26 dBm | |
| Global Navigation Satellite System (GNSS) | GPS GLONASS GALILEO |
| Hovering Accuracy Range | Vertical: ±0.1 m (with Vision Positioning), ±0.5 m (with GPS Positioning) |
| Horizontal: ±0.3 m (with Vision Positioning), ±1.5 m (with GPS Positioning) | |
| Gimbal | |
| Mechanical Range | Tilt: -110° to 35° |
| Roll: -35° to 35° | |
| Pan: -20° to 20° | |
| Controllable Range | Tilt: -90° to 0° (default setting) -90° to 20° (extended) |
| Stabilization | 3-axis (tilt, roll, pan) |
| Max Control Speed (tilt) | 100°/s |
| Angular Vibration Range | ±0.01° |
| Sensing System | |
| Downward | Hovering Range: 0.5m - 10m |
| Operating Environment | Non-Reflective, Discernable Surfaces |
| Diffuse Reflectivity (> 20%,such as Cement Pavement) | |
| Adequate Lighting (lux > 15, Normal Exposure Environment of Indoor Fluorescent Lamp) | |
| Camera | |
| Sensor | 1/2.3” CMOS |
| Effective Pixels: 12 MP | |
| Lens | FOV: 83° |
| 35 mm format equivalent: 24 mm | |
| Aperture: f/2.8 | |
| Focus range: 1 m to ∞ | |
| ISO | Video: |
| 100-3200 (Auto) | |
| 100-3200 (Manual) | |
| Photos: | |
| 100-3200 (Auto) | |
| 100-3200 (Manual) | |
| Shutter Speed | Electronic Shutter: 4-1/8000 s |
| Max Image Size | 4:3: 4000x3000 |
| 16:9: 4000x2250 | |
| Still Photography Modes | Single Shot |
| Interval: JPEG: 2/3/5/7/10/15/20/30/60 s | |
| JPEG RAW: 5/7/10/15/20/30/60 s | |
| Auto Exposure Bracketing (AEB): 3 bracketed frames at 2/3 EV Bias | |
| Panorama: Sphere, 180°, and Wide | |
| Video Resolution | 4K: 3840x2160 @ 24/25/30fps |
| 2.7K: 2720x1530 @ 24/25/30/48/50/60fps | |
| FHD: 1920x1080 @ 24/25/30/48/50/60fps | |
| Max Video Bitrate | 100 Mbps |
| Zoom Range | 4K: 2x |
| 2.7K: 3x | |
| FHD: 4x | |
| QuickShot Modes | Dronie, |
| Helix, | |
| Rocket, | |
| Circle, | |
| Boomerang | |
| Supported File Formats | FAT32 (≤ 32 GB) |
| exFAT (> 32 GB) | |
| Photo Formats | JPEG/DNG (RAW) |
| Video Formats | MP4 (H.264/MPEG-4 AVC) |
| Remote Controller & Video Transmission | |
| Operating Frequency | 2.400-2.4835 GHz, 5.725-5.850 GHz |
| Max Transmission Distance | 10 km (FCC) |
| 6 km (CE) | |
| 6 km (SRRC) | |
| 6 km (MIC) | |
| Operating Temperature | -10° to 40°C |
| Battery Capacity | 5200 mAh |
| Voltage | 1200 mA 3.6 V (Android) |
| 700 mA 3.6 V (iOS) | |
| Supported Mobile Device Size | 180mm x 86mm x 10mm |
| Supported USB Port Types | LightningMicro USB (Type-B) USB-C |
| Video Transmission System | OcuSync 2.0 |
| Live View Quality | Remote Controller: 720p/30fps |
| Max Bitrate | 8 Mbps |
| Latency | About 200 ms |
| Charger | |
| Input | 100-240 V, 50/60 Hz, 0.5 A |
| Output | 12V 1.5 A / 9V 2A / 5V 3A |
| Rated Power | 18 W |
| Intelligent Flight Battery | |
| Battery Capacity | 2250 mAh |
| Voltage | 7.7 V |
| Charging Voltage Limit | 8.8 V |
| Battery Type | LiPo 2S |
| Energy | 17.32 Wh |
| Weight | 86.2 g |
| Charging Temperature | 5°C to 40°C |
| Max Charging Power | 29 W |
| Package Contents | 1x Aircraft |
| 1x Remote Controller | |
| 1x Intelligent Flight Battery | |
| 1x Pair of Spare Propellers | |
| 1x USB Type-C Cable | |
| 1x Gimbal Protector | |
| 1x RC Cable (USB Type-C Connector) | |
| 1x RC Cable (Lightning Connector) | |
| 1x RC Cable (Standard Micro-USB Connector) | |
| 1x Pair of Spare Control Sticks | |
| 6x Spare Screw | |
| 1x Screwdriver | |
| Warranty Information | |
| Warranty | 1 Year Warranty |
