| SPECIFICATIONS | |
| Brand | EPSON |
| Model | FX-2190N |
| Series | Dot Matrix |
| Printing Method: | 9-pin, serial impact dot matrix |
| Print Direction | Bidirectional logic seeking for text and graphics printing. Unidirectional text or graphics printing can be selected using software commands. |
| Print Speed | Ultra Speed Draft: 680 cps (12 cpi); 566 cps (10 cpi) | High Speed Draft: 559 cps (10 cpi) | Draft: 419 cps (10 cpi) | Near Letter Quality: 104 cps (10 cpi) | (Note: Normal print speed is achieved when printer safety cover is fully closed) |
| Character Sets: | 13 character tables | 13 international character sets |
| Resident Bitmapped Fonts | Ultra Speed Draft: 10, 12 cpi | High Speed Draft: 10, 12, 15, 17, 20 cpi | Draft: 10, 12, 15, 17, 20 cpi | Near Letter Quality (Roman / Sans Serif): 10, 12, 15, 17, 20 cpi, proportional |
| Bar Code Fonts | EAN-13, EAN-8, Interleaved 2 of 5, UPC-A, UPC-E, Code 39, Code 128, POSTNET, Codabar (NW-7), Industrial 2 of 5, Matrix 2 of 5 |
| Characters per Line | 136 characters at 10 cpi |
| Line Spacing | 6 lines per inch default |
| Formatting | 1/6-inch or programmable in 1/432-inch increments | 8 lpi option available on FX-2190 Okidata Mode only | Paper Handling |
| Forms | Continuous multipart, original plus 5 carbonless copies, 1 + 6 copies with pull tractor, maximum thickness .018" |
| Envelopes | No. 6 envelopes: 6.5" x 3.6" | No. 10 envelopes: 9.5" x 4.1" |
| Width | Single sheets: 3.9" to 16.5" | Continuous: 4" to 16.0" | Cut-sheet feeder: 7.2" to 16.5" |
| Length | Single sheets: 3.9" to 14.3" | Continuous: 4" to 22" | Cut-sheet feeder: 10.1" to 14" |
| Labels | Minimum: 2.5" x 0.94" |
| Roll paper | 8.5" width |
| Paper Feed Speed | 62 millisecond per 1/6" | 5" per second, continuous feed |
| Paper Path | Manual insertion: Front or rear in, top out | Cut sheet feeder: Top in, top out | Tractor: Front, rear or bottom in, top out | Pull push tractor: Front or rear in, top out |
| Software Drivers | Windows 95, 98, 2000, Me, XP and NT 4.0 |
| Printer Language | Epson ESC / P | IBM PPDS | Okidata Microline (FX-2190 Okidata Mode only) |
| Interface | Bidirectional Parallel (IEEE 1284 Nibble Mode supported) | USB 1.1 | EpsonNet 10 / 100Base-TX Ethernet Print Server |
| Input Buffer | 128 KB |
| Control Panel | Functions: Font, pitch, pause, tear off, bin selection, line feed, form feed, load, eject, micro adjust, top-of-form adjustment, panel lockout, reset, menu, default setting selection |
| Sound Level | 55 dB(A) (ISO 7779 pattern) |
| Dimensions | 23.2" x Depth 13.8" x 6.1" (W x D x H) |
| Weight | 21.2 lb | Reliability |
| Total Print Volume | 52 million lines (not including printhead) |
| MTBF | 20,000 POH (25% duty cycle) |
| Print head life | 400 million characters at 14 dots / character |
| Ribbon life | 12 million characters at 14 dots / character | Warranty Information |
| Warranty | 12 Month Warranty |
| Manufacturer's Site | Visit the manufacturer's website |
|---|---|
| Product Link | Visit the manufacturer's page for this product |
