| SPECIFICATIONS | |
| Brand | Fractal Design |
| Series | Celsius Series |
| Model | FD-WCU-CELSIUS-S24-BK |
| Fan Specifications | |
| Fan Type | Fractal Design Dynamic X2 GP-12 PWM |
| Rotational Speed | 500 - 2000 RPM |
| Bearing Type | LLS Bearing |
| PWM Control | Yes |
| Acoustic Noise | 32.2 dB(A) (Full Speed) |
| Maximum Air Flow | 148.8 m3/h, 87.6 CFM |
| Maximum Static Pressure | 2.30 mm H2O |
| Input Voltage | 12 V DC |
| Maximum Input Current | 0.2 A |
| MTBF | 100 000 Hours |
| Pump Specification | |
| Rotational Speed | 1950 - 3150 RPM |
| Bearing Type | Ceramic Bearing and Shaft |
| PWM Control | Yes |
| Acoustic Noise | 20.0 dB(A) (Full Speed) |
| Maximum Pressure (50°C) | 1m H2O, 1.45 PSI |
| Input Voltage | 12 V DC |
| Input Current | 0.15 A (Without Fans) |
| Rated Input Power | 6.6 W (With Fans) |
| MTTF | 50 000 Hours |
| Radiator Specifications | |
| Housing Material | Aluminium |
| Fin Material | Aluminium |
| Port Threads | G 1/4" |
| Fan Screw Threads | UNC 6-32 |
| Dimensions | 284 x 122 x 31 mm |
| General | |
| Coldplate Technology | 5th Generation |
| Coldplate Material | Copper |
| Additional Sound Dampening | Integrated |
| Thermal Paste | Pre-Applied, High Thermal Conductivity |
| Fittings | Block Side: Durable Metal Fittings, Non-Removable |
| Radiator Side: Durable Metal Fittings, G 1/4" Thread | |
| Tube Length | 400 mm |
| Tube Material | Sleeved Low-Permability Rubber Tubes |
| Fan Control | Integrated Dual Mode |
| Sockets Supported | Intel: 1700 / 1150 / 1151 / 1155 / 1156 / 1200 / 1366 / 2011 / 2011-v3 / 2066 (Via Included 2011-v3 Kit) |
| AM5/ AM2 / AM2+ / AM3 / AM3+ / AM4 / FM1 / FM2 / FM2+ / TR4 (Via Included Bracket in AMD Threadripper Box) | |
| Package Contents | Celsius S24 System |
| 2 pcs Dynamic X2 GP-12 PWM Fans | |
| Multilingual User Manual | |
| Mounting Hardware For All Listed Sockets | |
| Fan and Radiator Mounting Screws | |
| Warranty Information | |
| Warranty | 5 Year Warranty |
| Manufacturer's Site | Visit the manufacturer's website |
|---|---|
| Product Link | Visit the manufacturer's page for this product |
Wootware X399 Threadripper - Custom Performance Edition E-ATX Desktop PC
From: R30,278.00
To: R73,044.00
Out of stock
- Suprised Me - Sean, 10 April 2019
I recently bought this cooler as I upgraded my system to an AMD AM4 CPU and wanted to test out overclocking with it
Upon pushing it higher I was reaching around 89 degrees on cinebench (4.2ghz 1.34V on Ryzen 2600)
After installing this cooler I sat around 55 degrees maximum with the radiator mounted on the front of my case, which competes with some of the more expensive coolers out there
If you looking to get into AIO Water Cooling I would highly recommend this as your first - Simple, well built, quiet and cool - Andre, 8 April 2019
As the other Andre said.
Runs my i7-9700k at 60deg under full gaming loads without making a sound. Around 30/40 on idle in the SA summer. When all other fans are running very slow the pump is audible, but you have to listen carefully close to the case.The thing feels so well built I really trust it.
I love the simplicity, just the two tubes and one header cable, and two quality fans. Installation was pretty simple too, with pre-applied thermal paste you just take off the plastic cover and stick it on. This does mean you will need to buy separate thermal paste if you want to take it off and put it back. - Just Buy It - Andre, 17 March 2019
From 70's plus under load with my stock wraith stealth cooler to under 50 with the S24.
Don't bother looking at these other mainstream brands. Simple,elegant, minimal = Fractal Design
