| SPECIFICATIONS | |
| Brand | HP |
| Series | Docking Station Series |
| Model | G5 USB 5Gbps Type-C Docking Station (5TW10AA) |
| Protocol | USB 3.2 Gen 1 |
| Interface | USB Type-C, Thunderbolt USB Type-C Compatible |
| Power Delivery | Up to 100W to supported devices |
| Compatibility | Compatible with Thunderbolt 3.0 devices |
| Compatible with Thunderbolt 4.0 / USB4 devices | |
| Compatible with Non-HP USB Type-C devices (limitations may apply) | |
| Displays | |
| DisplayPort | 2x DisplayPort 1.4 Ports, Supporting up to UltraHD 4K (3840x2160) 60Hz displays, Supports HDCP 2.2 and HDR with audio |
| HDMI | 1x HDMI 2.0 Port, Supporting up to UltraHD 4K (3840x2160) 60Hz displays, Supports HDCP 2.2 and HDR |
| Monitor Support Matrix | |
| Host Supports DisplayPort 1.4 with DSC | 3x FHD @ 60 Hz |
| 3x QHD @ 60 Hz | |
| 3x 4k @ 60 Hz | |
| Host Supports DisplayPort 1.3/1.4 | 3x FHD @ 60 Hz |
| 3x QHD @ 60 Hz | |
| 2x 4K @ 60 Hz | |
| Host Supports DisplayPort 1.2 | 3x FHD @ 60 Hz |
| 2x QHD @ 60 Hz | |
| 1x 4K @ 60 Hz | |
| Apple Mac Systems | 1x Display up to UltraHD 4K @ 60Hz |
| Connectivity | |
| Front & Side Ports | 1x USB Type-C 10Gbps USB Type-C Downstream Port (Front) |
| 2x USB 10Gbps Type-A Downstream Ports (Side) | |
| 1x 3.5mm Combination Audio Jack (Side) | |
| Rear Ports | 2x USB 10Gbps Type-A Downstream Ports (Rear) |
| 2x DisplayPort 1.4 Ports (Rear) | |
| 1x HDMI 2.0 Port (Rear) | |
| 1x Gigabit Ethernet RJ-45 LAN Port | |
| 1x Security Lock Slot (Rear) | |
| General | |
| Power Adapter | HP AC Barrel Power Adapter included |
| Security | Kensington Lock Slot (Rear) |
| Dimensions | 121.92 x 121.92 x 44.95mm (D x W x H) |
| Advanced Features (Windows Only) | MAC Address pass-through |
| Wake-On-Lan | |
| Wake-On-Dock (HP laptops only) | |
| Integrated Power button | |
| Audio Passthrough Support | |
| Supported Platforms | Windows 11 |
| Windows 10 | |
| ChromeOS v92.0.4515.157 | |
| ChromeOS M92 (HP notebooks only) | |
| ChromeOS M93 (HP notebooks only) | |
| ThinPro 8.0 | |
| Windows 10 IoT Enterprise LTSC 2021 | |
| macOS Monterey v12.0 | |
| macOS Big Sur 11.5.2 | |
| Tested Third-Party Devices | Apple MacBook Pro 13 2022 (M2) |
| Dell Latitude 5540 2022 (11th Gen Intel Core) | |
| Dell Latitude 7430 2022 (12th Gen Intel Core) | |
| Dell XPS 13 2022 (12th Gen Intel Core) | |
| Lenovo ThinkPad X1 Carbon Gen 9 2021 (11th Gen Intel Core) | |
| Lenovo ThinkPad X1 Carbon Gen 10 2022 (12th Gen Intel Core) | |
| Warranty Information | |
| Warranty | 1 Year Warranty |
