| SPECIFICATIONS | |
| Brand | Intel |
| Series | Granite Rapids CPU's |
| Model | PK8072006269900 |
| Total Cores | 64 |
| Total Threads | 128 |
| Max Turbo Frequency | 3.9 GHz |
| All Core Turbo Frequency | 3.6 GHz |
| Processor Base Frequency | 2.4 GHz |
| Cache | 336 MB |
| UPI Speed | 24 GT/s |
| Max Number Of UPI Links | 4 |
| TDP | 350W |
| Speed Select Performance Profile | 6767P(0): 64 Cores, 2.40GHz Base, 350W TDP, Server Mode |
| 6767P(1): 64 Cores, 2.80GHz Base, 350W TDP, Compute Mode | |
| Supplemental Information | |
| Marketing Status | Launched |
| Launch Date | Q1'25 |
| Embedded Options Available | No |
| Memory Specifications | |
| Max Memory Size | 4TB |
| Memory Types | DDR5 6400 MT/s |
| MRDIMM 8800 MT/s | |
| Maximum Memory Speed | 8000 MT/s |
| Max Number Of Memory Channels | 8 |
| ECC Memory Supported | Yes |
| Expansion Options | |
| Scalability | 2S |
| PCI Express Revision | 5.0 |
| Max Number Of PCI Express Lanes | 88 |
| Package Specifications | |
| Sockets Supported | FCLGA4710 |
| Package Carrier | E2A |
| DTS Max | 101°C |
| TCASE | 81°C |
| Package Size | 77.5 x 56.5 mm |
| Advanced Technologies | |
| QuickAssist Technology (QAT) | 4 Default Devices |
| Dynamic Load Balancer (DLB) | 4 Default Devices |
| Data Streaming Accelerator (DSA) | 4 Default Devices |
| In-Memory Analytics Accelerator (IAA) | 4 Default Devices |
| Advanced Matrix Extensions (AMX) | Yes |
| Speed Select Technology - Core Power | Yes |
| Speed Select Technology - Turbo Frequency | Yes |
| Deep Learning Boost On CPU | Yes |
| Speed Select Technology - Performance Profile | Yes |
| Speed Select Technology - Base Frequency | Yes |
| High Priority Cores | 24 |
| High Priority Core Frequency | 2.50 GHz |
| Low Priority Cores | 40 |
| Low Priority Core Frequency | 2.00 GHz |
| Resource Director Technology (RDT) | Yes |
| Speed Shift Technology | Yes |
| Turbo Boost Technology | 2.0 |
| Hyper-Threading Technology | Yes |
| Transactional Synchronization Extensions | Yes |
| 64 | Yes |
| Instruction Set Extensions | AMX |
| SSE4.2 | |
| AVX | |
| AVX2 | |
| AVX-512 | |
| Number Of AVX-512 FMA Units | 2 |
| Volume Management Device (VMD) | Yes |
| Security & Reliability | |
| Trust Domain Extensions (TDX) | Yes |
| Secure Key | Yes |
| Crypto Acceleration | Yes |
| QuickAssist Software Acceleration | Yes |
| Platform Firmware Resilience Support | Yes |
| Control-Flow Enforcement Technology | Yes |
| Total Memory Encryption - Multi Key | Yes |
| MK-TME Total | 2048 |
| Total Memory Encryption | Yes |
| AES New Instructions | Yes |
| Software Guard Extensions (SGX) | Yes |
| Default Maximum Enclave Page Cache (EPC) Size For SGX | 512GB |
| OS Guard | Yes |
| Trusted Execution Technology | Yes |
| Execute Disable Bit | Yes |
| Boot Guard | Yes |
| Run Sure Technology | Yes |
| Mode-Based Execute Control (MBEC) | Yes |
| Virtualization Technology (VT-x) | Yes |
| Virtualization Technology For Directed I/O (VT-d) | Yes |
| VT-x With Extended Page Tables (EPT) | Yes |
| Warranty Information | |
| Warranty | 3 Year Warranty |
| Manufacturer's Site | Visit the manufacturer's website |
|---|---|
| Product Link | Visit the manufacturer's page for this product |
