| SPECIFICATIONS | |
| Brand | J5Create |
| Series | Mini Dock Series |
| Model | JCA379 |
| General | |
| Host Connector | USB-C Male |
| Video Output | HDMI |
| Power Source | Bus-Powered Or Self-Powered |
| Audio Supported | Yes |
| Ports | 1x USB-C PD For Upstream Charging |
| 1x HDMI Output | |
| 1x USB 3.0 Gen 1 Type-A 5 Gbps | |
| Performance | |
| Maximum Display Resolution | 3840 x 2160 |
| Maximum Display Refresh Rate | 30 Hz |
| Maximum Data Transfer Rate | 5 Gbps |
| Displays Supported | 1 |
| Audio Channel | HDMI 2.1 |
| Features | Plug and Play – No Software Or Drivers Required |
| USB 3.0 SuperSpeed | |
| Data Transfer Rates Up to 5 Gbps | |
| Hot-Swappable Connection/Disconnection Without Powering Down | |
| DisplayPort Alt Mode For HDMI | |
| Supports Up to 3840 x 2160 @ 30 Hz Resolution | |
| Power | |
| Power Delivery | Up to 100W Via USB-C |
| Power Consumption | ≥ 350 mA |
| Input Current | Up to 5A |
| Input Voltage | Up to 20V |
| Output Current | Up to 4.25A |
| Output Voltage | Up to 20V |
| Physical Specifications | |
| Colour | Silver |
| Enclosure Type | ABS Plastic |
| Cable Length | 20cm |
| Product Dimensions(L x W x H) | 75.4 x 37.8 x 15.2 mm |
| Product Weight | 40g |
| Storage Temperature | |
| Storage Humidity | 85% Non-Condensing |
| Operating Temperature | 0 to 47°C |
| Operating Humidity | 85% Non-Condensing |
| Warranty Information | |
| Warranty | 2 Year Warranty |
| Manufacturer's Site | Visit the manufacturer's website |
|---|---|
| Product Link | Visit the manufacturer's page for this product |
