| SPECIFICATIONS | |
| Brand | Lalela |
| Series | Inverter Trolley |
| Model | LAL-600L |
| Inverter Output | |
| Rated Power | 600VA / 600W |
| Waveform | Pure Sine Wave |
| Nominal Output Voltage RMS | 230VAC |
| Output Voltage Regulation | 101-18% |
| Output Frequency | 50Hz / 60Hz ± 1Hz |
| Inverter Efficiency (Peak) | >90% |
| Line Mode Efficiency | >95% |
| Typical Transfer Time | Typical <10ms , 15ms max |
| AC Input | |
| Voltage | 230VAC |
| Voltage Range | 184 - 278VAC ± 3% |
| Frequency Range | 45 - 65Hz ± 2Hz |
| Battery | |
| Nominal Input Voltage | 12VDC |
| Low Battery Cutoff | 11.5VDC(LI) |
| Low Battery Alarm | 12.0VDC(LI) |
| Low Battery Voltage Recover | 12.8VDC(LI) |
| High Battery Voltage Recover | 14.3VDC(LI) |
| High Battery Voltage Cutoff | 14.8VDC(LI) |
| Charger | |
| Charger Voltage Boost | 14.4VDC(LI) |
| Charger Voltage Standby | 14.4VDC(LI) |
| Charging Current | 10A/ 15A± 2A @ 12V |
| Overcharge Protection S.D. | 15.5VDC |
| Bypass And Protection | |
| Nominal Input Frequency | 50Hz / 60Hz (auto detection] |
| Overload Protection (SMPS Load) | FUSE |
| Output Short Circuit Protection | 7A |
| Bypass Fuse Rating | 7A |
| Max Bypass Current | 7A |
| Mechanical Specification | |
| Dimensions | 320 x 231 x 96 mm |
| Warranty Information | |
| Warranty | 1 Year Warranty |
| Manufacturer's Site | Visit the manufacturer's website |
|---|---|
| Product Link | Visit the manufacturer's page for this product |
