| SPECIFICATIONS | |
| Brand | Lenovo |
| Series | ThinkPad |
| Model | Thunderbolt 4 Smart Dock Gen 2 7500 |
| Manufacturer Part Number | 40BE0135SA |
| Product Type | Docking Station |
| Colour | Black |
| Connectivity | |
| Upstream Connectivity | Thunderbolt 4 40Gbps Upstream Connectivity |
| USB Ports | 4 x USB-A 3.2 Gen 2 and 2 x USB-C 3.2 Gen 2 Ports |
| Front USB Ports | 2 x USB-A 3.2 Gen 2 (Always-On, 12W); 2 x USB-C 3.2 Gen 2 (Always-On, 15W) |
| Rear USB Ports | 2 x USB-A 3.2 Gen 2 (5W); 1 x Thunderbolt 4 Full-Function Port (15W) |
| Integrated Host Cable | 1m Integrated Thunderbolt 4 Host Cable |
| Ethernet | 1 x 2.5Gbps Ethernet |
| Network Features | Wake-on-LAN, PXE Boot and MAC Address Pass-Through on Compatible ThinkPad Notebooks |
| Security Lock Slots | 1 x MicroSaver Lock Slot and 1 x NanoSaver Lock Slot |
| Video Output | |
| Video Ports | 2 x DisplayPort 1.4, 1 x HDMI 2.1 and 1 x Thunderbolt 4 Full-Function Port |
| Display Support | |
| Maximum Display Configuration | 4 x 4K @60Hz Displays |
| Single High-Resolution Display | 1 x 8K @60Hz Display |
| Dual High-Refresh Displays | 2 x 4K @144Hz Displays |
| Maximum External Displays | 4 |
| Power | |
| Power Delivery | PD 3.1 with up to 100W Output |
| Included Power Adapter | 135W Power Adapter Included |
| Output Power | 100W |
| Input Power | 135W |
| Charging Port | DC-IN |
| Power Button | Yes |
| Software and Compatibility | |
| Dock Management | Lenovo Accessories Fleet Manager Cloud-Based Dock Management |
| Cloud Service | Amazon AWS |
| Supported Operating Systems | Windows 10 or Later, Linux and macOS 15 Sequoia or Later |
| Platform Certification | Intel Evo |
| General | |
| Product Dimensions | 220 x 80 x 30mm (W x D x H) |
| Product Weight | 547.5g Including Integrated Cable |
| Package Dimensions | 237.8 x 141 x 75.8mm (W x D x H) |
| Packaged Weight | 1.195kg |
| Package Contents | ThinkPad Thunderbolt 4 Smart Dock Gen 2 7500 with Integrated 1m Thunderbolt 4 Cable |
| 135W Power Adapter | |
| User Guide | |
| Exterior Casing | 90% Post-Consumer Recycled Material |
| Packaging | 90% Recycled, Plastic-Free, FSC-Certified Packaging |
| Sustainability Certification | TUV Carbon Footprint Certified |
| Identifiers | |
| EAN | 5715328283619 |
| Warranty Information | |
| Warranty | 3 Year Warranty |
| Manufacturer's Site | Visit the manufacturer's website |
|---|---|
| Product Link | Visit the manufacturer's page for this product |
