| SPECIFICATIONS | |
| Brand | PCBuilder |
| Series | CUBE |
| Model | PCB_CUBE_100U12G_OFFICE |
| Product Type | Mini PC |
| Colour | Black |
| Operating System | |
| Installed OS | Microsoft Windows 11 Pro |
| Processor | |
| Processor | Intel Core 3 100U |
| Cores | 6 |
| Threads | 8 |
| Cache | 10MB |
| Maximum Frequency | Up to 4.70GHz |
| Graphics And Display | |
| GPU | Integrated Intel Graphics |
| Maximum Published Output | Up to 7680 × 4320 at 60Hz through USB4 Type-C |
| Supported Displays | Up to three display outputs |
| Memory | |
| Installed Memory | 12GB |
| Installed Topology | 1 × 12GB SO-DIMM |
| Memory Type | DDR5 |
| Installed Speed | 5600MHz |
| Slots | 2 × DDR5 SO-DIMM, dual-channel capable |
| Maximum Published Capacity | Up to 96GB at 5200MHz |
| Storage | |
| Installed Drive | 512GB M.2 NVMe SSD |
| Installed Drive Generation | PCIe Gen 3 |
| Storage Slots | 2 × M.2 PCIe 4.0 NVMe slots |
| Connectivity And Ports | |
| Wi-Fi | Intel Wi-Fi 6, 802.11a/b/g/n/ac/ax |
| Bluetooth | Bluetooth 5.2 |
| Front Audio | 1 × 3.5mm dual line-out/microphone-in |
| Front USB-C | 1 × USB4 Type-C, up to 40Gb/s |
| Front USB-A | 2 × USB 3.2, up to 10Gb/s |
| Rear USB-A | 2 × USB 3.2, up to 10Gb/s |
| Rear DisplayPort | 1 × DisplayPort, up to 3840 × 2160 at 144Hz |
| Rear HDMI | 1 × HDMI 2.1, up to 3840 × 2160 at 60Hz |
| Rear Ethernet | 2 × RJ-45, published at 2.5Gb/s |
| Rear Power Input | 1 × DC input |
| Mounting | |
| VESA Support | 75mm and 100mm; bracket included |
| Security | |
| Kensington Slot | Yes |
| Power | |
| AC Input | 100–240V, 50/60Hz |
| Adapter Output | 65W, 19V/3.42A |
| Physical Aspects | |
| Material | PC and ABS |
| Dimensions | 13 × 12.7 × 4.7cm |
| Product Weight | 470g |
| Operating Temperature | 0°C to 40°C |
| Box Contents | |
| Mini PC | PCBuilder CUBE configured system ×1 |
| Power | AC adapter ×1 |
| Mounting | VESA bracket, four M4 screws and two M3 screws |
| Documentation | User manual ×1 |
| Warranty Information | |
| Warranty | 2-Year Warranty |
| Manufacturer's Site | Visit the manufacturer's website |
|---|---|
| Product Link | Visit the manufacturer's page for this product |
