| SPECIFICATIONS | |
| Brand | Phanteks |
| Series | Glacier One |
| Model | Glacier One 280 MP (PH-GO280MP_DBK01) |
| Specifications | |
| Supported Sockets | Intel: 115x / 1200 / 1366 / 2011 / 2011-v3 / 2066 |
| AMD: AM5/ AM4 / sTRX4* / TR4* | |
| *Threadripper bracket included with CPU | |
| Coldplate Material | Copper |
| Colour | Black |
| Pump | |
| Pump Speed | 2800 RPM +/- 300 (with 100% duty cycle) |
| Up to 3600 RPM with Out-of-Bound temperature sensing | |
| Pump Control | PWM |
| Pump PWM Cable Length | 245 mm |
| Power | 12V, 0.3A, 3.6W |
| Bearing | Ceramic bearing and shaft |
| Material | Copper, ABS plastic |
| Noise | 27 dBA |
| MTTF | 50,000 hours (typical use) |
| Cooling Liquid | Distilled water and Propylene Glycol mix |
| Thermal Paste | 4.5 W/m-k Pre-applied + Phanteks PH-NDC |
| Dimensions | 93 x 92 x 41 mm (LxWxH) |
| Infinity Mirror Cap | |
| D-RGB Style | Infinity mirror (tempered glass window) |
| D-RGB Type | 3-Pin Digital RGB LED strip (5V, data, ground) |
| LED Quantity | 14x LED Chips |
| D-RGB 3-Pin Cable Length | 5V, 0.42A, 2.1W |
| Power | 550 + 75 mm, daisy chain connector |
| Material | Tempered Glass, ABS Plastic |
| Tubes | |
| Length | 400mm |
| Outer Diameter | 11mm OD |
| Material | EPDM Rubber with black braided sleeves |
| Tube Clips | 3x Total |
| Fittings | Rotary Type |
| Fan Specifications | |
| Bearing Type | UFB (Updraft Floating Balance) Bearing |
| Blade Geometry | Seven blade design |
| Rated Voltage | DC 12V |
| PWM | Yes |
| Input Current | 0.23A |
| Input Power | 2.76W |
| Speed | 500 - 2000 +/-10% RPM |
| Max. Airflow | 24.3 - 93.05 CFM |
| Max. Air Pressure | 0.23 - 3.59 mmH2O |
| Noise Level | 18 - 39.1 dBA |
| Fan Connector | 4-Pin |
| Cable Length | 145mm Daisy-chain + 500mm extension cable |
| MTBF | 150,000 hours |
| Dimensions | 140 x 140 x 25 mm (LxWxH) |
| Radiator Specification | |
| Dimensions | 313 x 140 x 27 mm (WxHxD) |
| Material | Aluminium |
| FPI | 21 |
| Features | |
| Infinity Mirror Cap | Clean full cover design with easy and secure magnetic mounting |
| Tempered glass window with smooth and diffused D-RGB lighting | |
| Silent MP PWM Fans | High surface area fan blades for high pressure performance |
| Aerodynamically optimised for silent operation | |
| Cooled by Asetek | Gen 7 Asetek AIO platform delivers the best-in-class performance |
| Pump PWM control to optimise pump speed for acoustics and performance | |
| Out-of-bound temperature sensing enables the pump speed to automatically boost up to 3600 RPM when liquid temperature is above 60°C | |
| Built-in safety curve feature to ensure the liquid temperature stays within limits (60°C) for normal safe operation | |
| Maximum Clearance | Low profile pump cap for reduced height |
| Rotary fittings are located close to the pump to maximize RAM clearance | |
| Intuitive Installation | Compatible with all common Intel and AMD Sockets |
| Toolless and intuitive mounting system | |
| Thermal compound is pre-applied and comes included with an additional PH-NDC thermal compound for future re-installation | |
| Flexible tubing with durable braided sleeving | |
| 3x Tube Clips included to guide the tubing and fan cable for a clean and tidy case interior | |
| General | |
| Package Contents | Glacier One 280 MP cooler |
| Infinity Mirror Cap | |
| 280mm Radiator | |
| 2x 140mm MP fans | |
| 4-Pin PWM Splitter cable, 2x 80mm | |
| 4-Pin Fan PWM extension cable, 500mm | |
| 3-Pin D-RGB Motherboard adapter, 600mm | |
| PH-NDC Thermal compound | |
| 3x Tube clips | |
| Intel 115x / 1200 / 1366 backplate | |
| AMD AM4 Bracket (Intel bracket is pre-installed) | |
| 4x AM4 Stand-off | |
| 4x 115x/1200 Stand-off | |
| 4x 2066 Stand-off | |
| 4x Thumb nut | |
| 8x/12x 31mm Fan screws | |
| 8x/12x 5mm Radiator screws | |
| 8x/12x Washers | |
| Warranty Information | |
| Warranty | 6 Year Warranty |
| Manufacturer's Site | Visit the manufacturer's website |
|---|---|
| Product Link | Visit the manufacturer's page for this product |
- Great Cooler - Vuk, 28 April 2022
Paired it to a 3700X and am really happy. Stress testing using super pi, temps never went above 65c. Ran for an hour.
Highly recommend. - Works well with everything you need in it - Wayne, 15 December 2021
Works well with all the parts needed including extra heat past. The only issue is the RGB shrowd does not clip-on, but rests in place. So if you move the case it tends to fall off.
- Great cooler for the money! - Kyle, 29 September 2021
Looks great - subtle but sleek design
Good quality - feels very solid with everything very neatly assembled and packaged
Nice RGB - RGB isn't over the top and looks very crisp. Connected in daisy-chain with other Phanteks items with no issue
Solid thermal performance with no noise - Gaming temps on my 5800X have come down by about 10C compared to previous air cooler (Phanteks PH-TC14PE).
Thermals under full load are MUCH better as well.
Quite a bit cheaper, especially when on sale, when compared to similarly spec'd alternatives out there.
Switched out the fans for RGB Phanteks units and the cooler looks even more impressive now.
