| SPECIFICATIONS | |
| Brand | XFX |
| Series | Radeon RX 500 Series |
| Model | RX 560 Single Fan (RX-560P4SFGR) |
| Chipset | |
| GPU | Radeon RX 560 |
| Chipset Manufacturer | AMD |
| Interface | PCI-E 3.0 x16 |
| Base Clock | 1175 MHz |
| Boost Clock | Up to 1295 MHz |
| Stream Processors | 1024 |
| GPU Architecture | AMD 4th Generation GCN Architecture |
| Memory | |
| Effective Memory Clock | 7.0 GHz |
| Memory Size | 4GB |
| Memory Interface | 128-bit |
| Memory Type | GDDR5 |
| 3D API | |
| DirectX | 12 |
| OpenGL | 4.5 |
| Vulkan | Yes |
| Connectivity | |
| Ports | 1x DisplayPort 1.4 |
| 1x HDMI 2.0b | |
| 1x Dual Link DVI-D | |
| Maximum Digital Resolution | 4096 x 2160 |
| VR Ready | AMD LiquidVR Technology |
| General | |
| CrossFire Support | Yes |
| Features | 14nm FinFET Technology |
| PCI Express 3.0 Support | |
| DisplayPort 1.4 | |
| HDMI 2.0b | |
| AMD App Acceleration | |
| AMD Eyefinity multi-display technology | |
| AMD Frame Rate Target Control (FRTC) | |
| AMD FreeSync Technology | |
| AMD Radeon Crimson Software | |
| AMD TrueAudio Technology | |
| AMD Virtual Super Resolution (VSR) | |
| AMD WattMan | |
| AMD XConnect Ready | |
| Power Requirements | |
| Recommended Power Supply | 450W |
| Power Connector | 1x 6-Pin |
| Physical Aspects | |
| Form Factor | ATX |
| Slot Width | Dual Slot |
| Dimensions | 170 x 121 x 40 mm (LxWxH) |
| Warranty Information | |
| Warranty | 6 Month Warranty |
| Manufacturer's Site | Visit the manufacturer's website |
|---|---|
| Product Link | Visit the manufacturer's page for this product |
