Features
![]() | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
![]() | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
![]() | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
![]() | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
![]() | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
![]() | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
![]() | Product Description||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| SPECIFICATIONS | |
| Brand | TP-LINK |
| Model | Archer C9 | Hardware Features |
| Interface | 4 10/100/1000Mbps LAN Ports, | 1 10/100/1000Mbps WAN Port | 1 USB 3.0 Port + 1 USB 2.0 Port |
| Button | WPS/Reset Button, | Wireless On/Off Button, | Power On/off Button |
| Dimensions (W X D X H) | 221 X 86 X 168.5mm |
| Antenna | 3 dual band detachable antennas |
| External Power Supply | 12V/3.3A | Wireless Features |
| Wireless Standards | IEEE 802.11ac/n/a 5GHz | IEEE 802.11b/g/n 2.4GHz |
| Frequency | 2.4GHz and 5GHz |
| Signal Rate | 5GHz: Up to 1300Mbps | 2.4GHz: Up to 600Mbps |
| Reception Sensitivity | 5GHz: | 11a 6Mbps: -94dBm | 11a 54Mbps: -76dBm | 11ac HT20: -68dBm | 11ac HT40: -64dBm | 11ac HT80: -60dBm | 2.4GHz | 11g 54M: -77dBm | 11n HT20: -73dBm | 11n HT40: -71dBm |
| Transmit Power | CE: | <20dBm(2.4GHz) | <23dBm(5GHz) | FCC: | <30dBm |
| Wireless Functions | Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics |
| Wireless Security | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA-PSK2 encryption | Software Features |
| Quality of Service | WMM, Bandwidth Control |
| WAN Type | Dynamic IP/Static IP/PPPoE/ | PPTP(Dual Access)/L2TP(Dual Access)/BigPond |
| Management | Access Control | Local Management | Remote Management |
| DHCP | Server, Client, DHCP Client List, | Address Reservation |
| Port Forwarding | Virtual Server, Port Triggering, UPnP, DMZ |
| Dynamic DNS | DynDns, Comexe, NO-IP |
| VPN Pass-Through | PPTP, L2TP, IPSec |
| Access Control | Parental Control, Local Management Control, Host List, Access | Schedule, Rule Management |
| Firewall Security | DoS, SPI Firewall | IP Address Filter/MAC Address Filter/Domain Filter | IP and MAC Address Binding |
| Protocols | Supports IPv4 and IPv6 |
| USB Sharing | Support Samba(Storage)/FTP Server/Media Server/Printer Server |
| Guest Network | 2.4GHz guest network × 1 | 5GHz guest network × 1 | Others |
| Certification | CE, FCC, RoHS |
| Package Contents | AC 1900 Wireless Dual Band Gigabit Router Archer C9 | 3 detachable antennas | Power supply unit | Resource CD | Ethernet Cable | Quick Installation Guide |
| System Requirements | Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 7, Windows 8/8.1/10 | MAC OS, NetWare, UNIX or Linux |
| Environment | Operating Temperature: 0°C~40°C | Storage Temperature: -40°C~70°C | Operating Humidity: 10%~90% non-condensing | Storage Humidity: 5%~90% non-condensing | Warranty Information |
| Warranty | 12 Month Warranty |
| Manufacturer's Site | Visit the manufacturer's website |
|---|---|
| Product Link | Visit the manufacturer's page for this product |
