| General | |
| Brand | TP-Link Omada |
| Model | ES228GMP |
| Hardware Features | |
| Interface | 24x 10/100/1000 Mbps PoE+ RJ45 Ports (802.3af/at) |
| 2x 10/100/1000 Mbps RJ45 Ports | |
| 2x Gigabit SFP Slots | |
| Auto-Negotiation | |
| Auto MDI/MDIX | |
| Fan Quantity | 2 |
| Installation | Desktop |
| Rack Mounting | |
| Physical Security Lock | Yes |
| Power Supply | 100–240V AC, 50/60Hz |
| PoE Features | |
| Standard | 802.3af PoE |
| 802.3at PoE+ compliant | |
| PoE Ports | 24 |
| PoE Budget | 384W Total |
| 30W Max Per Port | |
| Features | Fast PoE |
| Perpetual PoE | |
| PoE Auto Recovery | |
| Up To 820ft PoE Transmission Distance | |
| Physical | |
| Jumbo Frame | 15 KB |
| Dimensions (W x D x H) | 440 mm x 330 mm x 44 mm |
| Surge Protection | ±6 kV in common mode for Ethernet Ports |
| Max. Power Consumption | 454.8 W (110V/60Hz) with 384 W PD connected |
| Performance | |
| Packet Buffer Memory | 4 Mbit |
| Switching Capacity | 56 Gbps |
| Packet Forwarding Rate | 41.66 Mpps |
| MAC Address Table | 8K |
| Software Features | |
| Quality of Service | Port-based QoS |
| 802.1p QoS | |
| DSCP QoS | |
| Priority Queues | 8 |
| Priority Schedule Mode | WRR (Weighted Round Robin) |
| Bandwidth Control | Port-Based Rating Limit |
| Storm Control | Multiple Control Modes (kbps/pps) |
| Broadcast/Multicast/Unknown-Unicast Control | |
| L2 Features | Static Link Aggregation |
| Loop Prevention | |
| Loopback Detection | |
| 802.3x Flow Control | |
| Port Mirroring (One-to-One, Many-to-One, Ingress/Egress/Both) | |
| Port Statistics (Port Mirror Status, Traffic Statistics) | |
| 802.1ab LLDP | |
| L2 Multicast | IGMP v1/v2/v3 Snooping |
| Fast Leave | |
| VLAN | MTU VLAN |
| Port-Based VLAN | |
| 802.1Q Tag VLAN (Max 32 VLAN Groups, 4K VID) | |
| Management Features | |
| Omada App | Yes (Requires Omada Hardware Controller, Cloud-Based Controller, or Software Controller) |
| Centralized Management | Omada Cloud-Based Controller |
| Omada Hardware Controller | |
| Omada Software Controller | |
| Cloud Access | Yes (Requires Omada Hardware Controller, Cloud-Based Controller, or Software Controller) |
| Zero-Touch Provisioning | Yes (Requires Omada Cloud-Based Controller) |
| Management Features | Web-based GUI |
| DHCP Client | |
| Cable Diagnostics | |
| Automatic Device Discovery | |
| Batch Configuration | |
| Batch Firmware Upgrading | |
| Unified Configuration | |
| Other | |
| Certification | FCC |
| CE | |
| RoHS | |
| Package Content | ES228GMP |
| Power Cord | |
| Mounting Brackets | |
| Rubber Feet | |
| Screws | |
| Installation Guide | |
| Operating Temperature | -5℃~45℃ (23℉~113℉) |
| Storage Temperature | -40℃~70℃ (-40℉~158℉) |
| Operating Humidity | 10%~90% non-condensing |
| Storage Humidity | 5%~90% non-condensing |
| ESD/EMP Protection | Air: ±8 kV |
| Contact: ±4 kV | |
| Warranty Information | |
| Warranty | 2 Year Warranty |
| Manufacturer's Site | Visit the manufacturer's website |
|---|---|
| Product Link | Visit the manufacturer's page for this product |
