| SPECIFICATIONS | |
| Brand | TP-LINK |
| Model | TL-MR3040 | Hardware Features |
| Interface | 1 10/100Mbps WAN/LAN port, USB 2.0 port for 3G/4G modem, a micro USB port for power supply |
| Button | Power On/Off Button, Reset Button, Operation Mode Switch |
| Power Supply | Internal 2000mAh rechargeable battery, 5VDC/1.0A external power adapter |
| Dimensions (W X D X H) | 100 x 62 x 16 mm |
| LED | Power, WLAN, Ethernet, Internet |
| Weight | 3.3 ounce (94g) |
| Antenna Type | Internal Antenna | Wireless Features |
| Wireless Standards | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Frequency | 2.4-2.4835GHz |
| Signal Rate | Up to 150Mbps |
| Transmit Power | <20dBm |
| Wireless Security | Support 64/128 bit WEP, WPA-PSK/WPA2-PSK,Wireless MAC Filtering, Enable/Disable SSID Broadcast | Software Features |
| Security | Firewall, VPN, ALG, IP&MAC Binding, DoS Protection |
| Operating Modes | 3G/4G Router, Travel Router (AP), WISP Client Router |
| WAN Type | Dynamic IP, Static IP, PPPoE/Russia PPPoE, Bigpand Cable, L2TP/Russia L2TP, PPTP/Russia PPTP |
| DHCP | DHCP server, DHCP Client List, Address Reservation |
| Port Forwarding | Virtual Server, Port Triggering, DMZ, UPnP |
| Access Control | Parental Control, Bandwidth Control, Loal Management, Remote Management, Access Schedule, Advanced Routing | Others |
| Certification | CE, FCC, RoHS |
| Package Contents | TL-MR3040 | Power Adapter | Li-Ion Battery | USB Cable | Ethernet Cable | Quick Installation Guide | Resource CD |
| System Requirements | Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 7, Windows 8, MAC OS, NetWare, UNIX or Linux. |
| Environment | Operating temperature:15°C~40°C | Storage Temperature: -20°C~50°C | Operating Humidity: 0%~75% non-condensing | Storage Humidity: 0%~75% non-condensing | Warranty Information |
| Warranty | 12 Month Warranty |
| Manufacturer's Site | Visit the manufacturer's website |
|---|---|
| Product Link | Visit the manufacturer's page for this product |
