| SPECIFICATIONS | |
| Brand | TP-LINK |
| Series | Powerline Extender |
| Model | AV600 (TL-WPA4220) |
| Hardware | |
| Standards and Protocols | HomePlug AV2, IEEE 1901, IEEE 802.3, IEEE 802.3u, IEEE 802.11b/g/n |
| Plug Type | EU |
| Interface | 2x 10/100Mbps Ethernet Port |
| Button | Pair, Reset, Wi-Fi/Wi-Fi Clone |
| Power Consumption | Maximum: 5.6W |
| Typical: 5.2W | |
| LED Indicator | Power, Powerline, Ethernet, Wi-Fi |
| Dimensions | 54mm × 40mm x 94mm |
| Range | Up to 300 meters/1000 feet over existing electrical wiring |
| Wireless | |
| Frequency | 2.4-2.4835GHz |
| Signal Rate | 11n: Up to 300Mbps(dynamic) |
| 11g: Up to 54Mbps(dynamic) | |
| 11b: Up to 11Mbps(dynamic) | |
| Reception Sensitivity | 270M: -68dBm@10% PER |
| 130M: -68dBm@10% PER | |
| 108M: -68dBm@10% PER | |
| 54M: -68dBm@10% PER | |
| 11M: -85dBm@8% PER | |
| 6M: -88dBm@10% PER | |
| 1M: -90dBm@8% PER | |
| Wireless Security | 64/128-bit WEP / WPA / WPA2,WPA-PSK / WPA2-PSK |
| Advanced Functions | Enable/DisableWireless Radio,WMM, Wireless Statistics |
| Transmission Power | CE:<20dBm(2.4GHz) |
| FCC:<30dBm | |
| Software | |
| Modulation Technology | OFDM (PLC) |
| Encryption | Powerline Security: 128-bit AES Encryption |
| Wireless Security: WPA-PSK / WPA2-PSK, WEP Encryptions | |
| General | |
| Certification | CE, RoHS |
| Package Contents | AV600 Powerline Wi-Fi Extender: 1 × TL-WPA4220 |
| 1x Ethernet Cable | |
| 1x Quick Installation Guide | |
| System Requirements | System Requirements: |
| Windows 10/8.1/8/7/Vista/XP, Mac OS, Linux | |
| System Requirements for tpPLC Utility: | |
| Windows 10/8.1/8/7/Vista/XP and Mac OS X (10.7 or later) | |
| Environment | Operating Temperature: 0 °C ~ 40 °C |
| Operating Humidity: 10% ~ 90% non-condensing | |
| Storage Humidity: 5% ~ 90% non-condensing | |
| Warranty Information | |
| Warranty | 1 Year Warranty |
| Manufacturer's Site | Visit the manufacturer's website |
|---|---|
| Product Link | Visit the manufacturer's page for this product |
- Does what it says on the tin - Dewan, 28 February 2025
Been using the AV600 adaptors in my apartment as running ethernet was not an option. Got this unit to improve wifi in the master bedroom. Syncing was quick, app is nicely laid out, worked as expected and was super quick to set up. Took not even 5 mins
