Product Description
Additional Information
Reviews (1)
| SPECIFICATIONS | |
| Brand | TP_LINK |
| Model | TL-WPA4220KIT | Hardware Features |
| Plug Type | EU, UK, US, AR |
| Standards and Protocols | HomePlug AV, IEEE802.3, IEEE802.3u, IEEE802.11b/g/n |
| Interface | 2*10/100Mbps Ethernet Port |
| Button | Pair, Reset, Wi-Fi/Wi-Fi Clone |
| Power Consumption | Maximum: 7.608W (220V/50Hz) | Typical: 7.216W (220V/50Hz) | Standby: 4.610W (220V/50Hz) |
| LED Indicator | PWR, PLC, ETH, Wi-Fi/Wi-Fi Clone |
| Dimensions ( W x D x H ) | 94×54×40mm |
| Range | 300 Meters over electrical circuit | Wireless Features |
| Frequency | 2.4-2.4835GHz |
| Signal Rate | 11n: Up to 300Mbps(dynamic) | 11g: Up to 54Mbps(dynamic) | 11b: Up to 11Mbps(dynamic) |
| Reception Sensitivity | 270M: -68dBm@10% PER | 130M: -68dBm@10% PER | 108M: -68dBm@10% PER | 54M: -68dBm@10% PER | 11M: -85dBm@8% PER | 6M: -88dBm@10% PER | 1M: -90dBm@8% PER |
| Wireless Security | 64/128-bit WEP / WPA / WPA2,WPA-PSK / WPA2-PSK |
| Advanced Functions | Enable/DisableWireless Radio,WMM, Wireless Statistics |
| Advanced Functions | Enable/DisableWireless Radio,WMM, Wireless Statistics |
| Transmission Power | CE: <20dBm(2.4GHz) | FCC: <30dBm | Software Features |
| Modulation Technology | OFDM (PLC) |
| Encryption | Powerline Security: | 128-bit AES | Wireless Security: | WEP, WPA/WPA2, WPA-PSK/WPA2-PSK Encryption | Others |
| Certification | CE, FCC, RoHS |
| Package Contents | Powerline Ethernet Adapter TL-WPA4220 & TL-PA4010 | 6.5 ft. (2 m) Ethernet cable (RJ45) | Resource CD | Quick Installation Guide |
| System Requirements | Windows 2000/XP/2003/Vista, Windows 7/8, Mac, Linux |
| Environment | Operating Temperature: 0°C~40°C | Storage Temperature: -40°C~70°C | Operating Humidity: 10%~90% non-condensing | Storage Humidity: 5%~90% non-condensing | Warranty Information |
| Warranty | 12 Month Warranty |
| Manufacturer's Site | Visit the manufacturer's website |
|---|---|
| Product Link | Visit the manufacturer's page for this product |
- Good range, bad DHCP - Johan, 14 September 2020
Works OK, but the WiFi DHCP doesn't play nice with my Netis router. I have to assign IP addresses manually if a device connects wirelessly. Wired Ethernet is fine though
