| SPECIFICATIONS | |
| Brand | Ubiquiti |
| Series | U-PoE |
| Model | U-PoE |
| Product Type | PoE Adapter |
| Power Output | 15W |
| Power & Electrical | |
| Output Voltage | 48V DC @ 0.32A |
| Rated Voltage | 100V-240V AC @ 50/60Hz |
| Input Current | 500mA Max. |
| Inrush Current | <100A Peak At 25°C |
| Efficiency | 84.25+% |
| Switching Frequency | 65 kHz |
| Output Ripple | 200mV pp |
| Line Regulation | ≤ 3% |
| Load Regulation | ≤ 5% |
| Networking & Interfaces | |
| Gigabit LAN Port | Yes |
| Data In / PoE | RJ45 Shielded Socket |
| 2-Pair Powering | Pins 4, 5 (+) And 7, 8 (-) |
| Protection & Surge Suppression | |
| Clamping Protection | 11V Data, 60V Power |
| Surge Protection | Difference And Common Mode |
| Max. Surge Discharge | 1500A (8/20 μs) Power |
| Peak Pulse Current | 36A (10/1000 μs) Data |
| Response Time | <1 ns |
| Shunt Capacitance | <5 pF Data |
| Compliance & Certifications | |
| AC Connector | IEC-320 C6 |
| NDAA Compliant | Yes |
| Certifications | CE |
| FCC | |
| IC | |
| UL | |
| CCC | |
| General | |
| Dimensions | 86 x 46 x 33 mm |
| Weight | 100 g |
| Storage Temperature | -30 To 70°C |
| Operating Temperature | 0 To 40°C |
| Operating Humidity | 10 To 95% Noncondensing |
| Warranty Information | |
| Warranty | 2 Year Warranty |
