| SPECIFICATIONS | |
| Brand | XFX |
| Series | RX 5600 XT |
| Model | THICC III Ultra (RX-56XT6TBD8) |
| Chipset | |
| GPU | Radeon RX 5600 XT |
| Chipset Manufacturer | AMD |
| Interface | PCI-E 4.0 x16 |
| Game Clock | 1660 MHz |
| Boost Clock | 1750 MHz |
| Stream Processors | 2304 |
| GPU Architecture | AMD RDNA |
| Memory | |
| Effective Memory Clock | 12 Gbps |
| Memory Size | 6GB |
| Memory Interface | 192-bit |
| Memory Type | GDDR6 |
| 3D API | |
| DirectX | 12 |
| OpenGL | 4.5 |
| Connectivity | |
| Ports | 3x DisplayPort 1.4 w/DSC |
| 1x HDMI 2.0b | |
| Maximum Digital Resolution | 4K 240Hz |
| 4K HDR 120Hz | |
| 8K HDR 60Hz | |
| VR Ready | Yes, Radeon VR Ready Premium |
| General | |
| Cooler | DD Fansink Cooling Technology |
| Features | RDNA Architecture |
| Advanced 2nd Gen 7nm GPU | |
| PCI Express 4.0 Support | |
| FidelityFX | |
| Displayport 1.4 w/ DSC | |
| Dolby TrueHD and DTS-HD Master Audio Support | |
| Video Streaming up to 8K | |
| AMD Radeon Image Sharpening | |
| AMD Radeon Anti-Lag | |
| AMD Virtual Super Resolution (VSR) | |
| AMD Relive | |
| AMD FreeSync | |
| AMD Frame Rate Target Control (FRTC) | |
| AMD Eyefinity Multi-Display Technology | |
| AMD Radeon Adrenalin Software 2020 | |
| AMD WattMan | |
| AMD Radeon Boost | |
| Power Requirements | |
| Minimum Recommended Power Supply | 450W |
| Power Consumption (TDP) | 170W |
| Power Connector | 1x 8-Pin, 1x 6-Pin |
| Physical Aspects | |
| Form Factor | ATX |
| Slot Width | Dual Slot |
| Dimensions | 326 x 148 x 44 mm (LxWxH) |
| Warranty Information | |
| Warranty | 2 Year Warranty |
| Manufacturer's Site | Visit the manufacturer's website |
|---|---|
| Product Link | Visit the manufacturer's page for this product |
