| SPECIFICATIONS | |
| Brand | XFX |
| Series | RX 5700 XT Series |
| Model | THICC III Ultra (RX-57XT8TBD8) |
| Chipset | |
| GPU | Radeon RX 5700 XT (Navi XL) |
| Chipset Manufacturer | AMD |
| Interface | PCI-E 4.0 x16 |
| Base Clock | 1810 MHz |
| Game Clock | 1935 MHz |
| Boost Clock | Up to 2025 MHz |
| Stream Processors | 2560 |
| GPU Architecture | AMD RDNA |
| Memory | |
| Effective Memory Clock | 14 Gbps |
| Memory Size | 8GB |
| Memory Interface | 256-bit |
| Memory Type | GDDR6 |
| 3D API | |
| DirectX | 12 |
| OpenGL | 4.5 |
| OpenCL | Yes |
| Vulkan | Yes |
| Connectivity | |
| Ports | 3x DisplayPort 1.4 w/ DSC |
| 1x HDMI 2.0b | |
| Maximum Digital Resolution | Up to 8K @60Hz |
| Up to 5K @120Hz | |
| VR Ready | Yes, AMD Radeon VR Ready Premium |
| General | |
| Features | 2nd Gen 7nm GPU |
| AMD FreeSync 2 HDR | |
| AMD Frame Rate Target Control (FRTC) | |
| AMD Eyefinity multi-display technology | |
| AMD WattMan | |
| AMD Relive | |
| AMD Virtual Super Resolution (VSR) | |
| Radeon Image Sharpening | |
| Radeon Anti-Lag | |
| FidelityFX | |
| Dolby TrueHD and DTS-HD Master Audio Support | |
| Up to 6 displays supported (may require the use of MST Hubs) | |
| Package Contents | 2x 8-Pin to 6-Pin power cable |
| 1x Driver disk installation guide | |
| Power Requirements | |
| Minimum Recommended Power Supply | 600W |
| Power Connector | 2x 8-Pin Connectors |
| Physical Aspects | |
| Form Factor | ATX |
| Slot Width | 2.8 Slot |
| Dimensions | 315 x 131 x 57 mm (LxWxH) |
| Warranty Information | |
| Warranty | 2 Year Warranty |
| Manufacturer's Site | Visit the manufacturer's website |
|---|---|
| Product Link | Visit the manufacturer's page for this product |
- Beautiful. And fast. - Johan, 12 October 2020
If vga cards were models...this would be a supermodel. It is STUNNING! Modern Warfare plays like I have never experienced. I have been a console gamer since my first Atari 2600 when I was 5 or 6. Now there is no turning back. Buy this. You will not regret it. Its worth every cent.
- So happy - Johan, 8 October 2020
Great card. Its beautiful so make sure your case shows it off. My very first pc build and this thing is amazing. Games look great. Play great. Money well spent. Fantastic service from wootware.
- This is a monster - literally - Morne, 13 September 2020
Firstly, this graphics card is monstrous ! (Seriously, make sure your case supports the dimensions) Secondly, this card packs a punch ! Super happy with the performance, I would advise to set a manual fan curve as it can get a bit toasty under full load, nothing too serious though.
- Really Good Card - Oluwabori, 7 September 2020
Run Quietly
Plays my games at 1440p High settings at 144fps, very close and sometimes higher
Low temps to0.
Card turbos to 2099mhz without overclocking.
Happy with my purchase. - Happy Chappy - Mogammad, 18 August 2020
A lot better cooling than my MSI Radeon RX 5700 XT MECH OC (what a #@# GPU) where core temps hardly go above 65 degrees Celsius on Stock. Good performance at a good price! Very happy with my purchase.Kudos to Wootware for their good service.Not my first purchase at Wootware and certainly not my last.
- Amazing value for money - Ryan, 17 August 2020
This card is amazing! Has worked great and runs nice and cool. Even on the warmer days, it stays boosted even after hours of gaming.
Just make sure you have enough case clearance, even in terms of card height. - Driver problems - Steven, 12 August 2020
I have had loads of problems with this card but most of them seem to be due to drivers.
I have been forced to install this version : Radeon Software Adrenalin 2020 Edition 20.1.4.
with this version I have had no blue screen while playing Warzone and I get to play on full graphic settings.
note: if I enable Radeon Relive it takes 60% of my GPU usage percentage and my game stutters when playing on ultimate settings.
no other games seem to give any problems and this card is beautiful!! can not wait for AMD to release proper drivers. - This thing is an inconspicuous beast - Damian, 11 August 2020
I have been thoroughly impressed with this GPU, after having used it for about a week or so now. It has been up to every single task I've thrown at it, it runs games on highest quality with ease, and does so extremely quietly. The cooling system is perfectly optimised to allow for full draw from the GPU at at a reasonably stable temperature with not even 50% fans, making it an ideal card for anyone who is noise sensitive. For the price, this card is absolutely worth the purchase!
- Excellent Cooling - Imrahn, 10 August 2020
A lot better cooling than my previous 5700 XT reference card where core temps hardly go above 65 degrees celsius on Stock. Good performance at a good price! Very happy with my purchase.
- One of the best - Seth, 10 August 2020
XFX have really done an amazing job with this card. The cooling is impeccable and sits in the 50's 60's and sometimes 70's when on a load. It can run anything maxed at 1080 and is overkill in many games. Only thing is this card is very very long and I had to remove a fan when installing it but it all fit in the meshify c with a few millimetres of clearance when the fan was back in. The driver issues that plagued AMD seem to all be gone and I've had no issues with the software.
Overall this is definitely one of the best cards you buy at the moment. - Exceeds Expectation - Michael, 10 August 2020
The graphics card has none of the issues of the Thicc ii and has exceeded my expectation. Able to run most modern titles on 1440p at high or ultra with 4K a definite option as well. Wootware will see me regularly due to the fast and efficient customer service I experience with them
- The thicc one - Jesse, 10 August 2020
Must say I am blown away by this card. No regrets when I moved from my 1070 to this. Runs well with my ryzen 7 2700. This card does run hot so be sure to create a custom fan curve in the AMD driver software. Other than that no problems from the card.
- fantsatic - Mohamed, 7 August 2020
This thiccboii can handle forza 4 1080p on ultra, with 50% utilization. fantastic value for money. just as good as a 2070 super in relative value in my opinion. chilled in terms of cooling too. very happy :)
- No Issues with the title. - Tommy, 3 August 2020
This is a beast of a card, It runs quietly even with three fans, typical Radeon you'll maybe need to tweak some setting to have everything running smooth. The speeds and graphics are great.
Be aware this card is wide! if you have a small board, be aware, I'm having issues accessing my SATA connectors die to the card-chassis size. - Amazing GPU - Alex, 8 July 2020
This card is better than expected. I would recommend this to anyone. Was a huge Green fan, but the Red machine has a price tag of Good GPU and the power of the 10k + GPU's. Thanks Wootware. Exceeded my expectations yet again.
- XFX RX5700XT - Willem, 8 July 2020
Great graphics card performance, great looking card. Plays high end titles at 100fps+ @ 1080p. No issues with input lag or screen tearing, fan noise remarkably low, well priced.
- Great card, decent price and so-so software - Wesley, 7 July 2020
The first thing you do is make sure that your case supports this length of card - trust me! Check out all the details Wootware provides on products related to measurements. I'm surprised nobody else has said it yet - this card deserves to be showcased - it is absolutely gorgeous to look at. Reminds me of an old american muscle car - plain but freaking gorgeous. Temps will not always be great because some of that beauty causes inefficient cooling - this has been proven by reputable guys - Steve @ Gamers Nexus for example. However, not a deal breaker. It needs two 8-pin power sources. The card itself I have no issues with - happy with my purchase. Software on the other hand... meh. I don't stream and don't want all the other fluff - I have a 4k TV I use as a monitor and I just want everything off as all I need is the SPEED, which the card provides in spades. It's a bit buggy and for my needs: useless. So still 4 stars.
- Great card - Liam, 5 July 2020
At first I had some issues regarding drivers, but I installed a recommended set of drivers and everything is perfect! The card keeps itself cool and can run all AAA games on ultra without much struggle. It's really worth the money if you're considering an RTX 2060 or higher. For some cases this card can compete with the 2070 super!
- Wow - David, 3 July 2020
I was very hesitant to buy a XFX GPU cause I've been an MSI fan boy since I can remember but Wow!
This card is amazing! All my games are on Ultra 2k res and I dont even feel a difference. Definitely bang for your buck and performs as good/better than the more expensive models. Just keep in mind that it is a BIG card so you gotta have space and a proper PSU.
No issues! - I find that it describes the product enough with all the information you need. - Jaco, 2 July 2020
So i upgraded from a Nvidia GForce 1050 ti to the Radeon RX 5700 XT and it is a huge jump, i did some research and found that the 5700 has the best price to/for performance. Its out performs the normal Nvidia 2060, 2060 Super and 2070, it competes neck and neck with the 2070 Super on fps on several benchmarks. This card is also cheaper than the 2070 Super. The thicc III is a little bit bigger than i expected (+-310mm in length) and had to modify my case as it was optimized for mini ATX build, also if you are a fan of no lights / RGB , this is for you as i have not seen any and it fits into my black build with minimal lights.
- Great - Mitchel, 29 June 2020
The XFX Thicc III blows other 5700XT's out of the water.
managed to get a 2185mhz boost with the auto overclock, while never going above 66°
while under full load... and the impressive part is that this was with fans running under 50%.
highly recommend this card, I've had zero driver issues which was the main concern with the 5700XT. - It’s a beast - Joshua , 26 June 2020
Card is a beast, such value for money!
- Very good card - Willie, 19 June 2020
I have been using my card for a few months now and it is running without any issues. I was worried about the amd driver issues, but I have not experienced any issues so far with this card. This is my first AMR/Radeon card, I have been on nVidia for years. And I can say I am not disappointed at all. This is a very good card.
- Best value for money - Reinhard, 28 May 2020
What an amazing card, it exceeded my expectations and baffled me completely especially with the new radeon software. I obtain 200+ frames in almost all of my games and around an average of 170fps in Modern warfare Multiplayer at max graphics settings with multiple displays running at once.
The most important setting to change is the fan curve of the GPU. I use 35% at 30deg; 45% at 40deg; 55% at 50deg; 65% at 60deg and 75% at 70deg. With this curve the maximum temperature that I reached at room temp was 68deg after 5 hours of constant gaming.
This card is most definitely worth the money and destroys all other cards which is listed at the same price. - 5700 XT is great value for money - Dihan, 8 May 2020
Bought this card about a week ago now and I am very happy with how it's performing. Thermals and noise are good, so is the performance. Boosts to around 2 Ghz most of the time.
Something of note for new buyers, make sure this card will fit in your case. It's a very "LONG" boy. - Solid Card - Roan, 6 April 2020
Great performance for the price. Haven't noticed any noise issues in my case. It is a BIG card. Make sure you have ample space. Might require a little bit of support so that it doesn't sag in its PCI slot. Two 8-pin connectors so make sure your PSU can supply it.
- 10/10 - Jonathan, 30 March 2020
Great graphics card. A mammoth in size but runs cool and smashes any game on ultra/max at 1080p - even with superscaling! I did a lot of research into this card and it's one of the better RX 5700 XTs in terms of performance and low running temperatures. It is a power hungry monster but still uses less than my old R9 390 hehe...
Wootware had an amazing turnaround on the product - I got the card one day later. Just a note though: the AMD Rewards is having trouble with their authentication software (that checks for your graphics card), so you need to log a query with their support to get your games redeemed. - Great GPU, Early Teething Issues - Channing, 25 February 2020
I purchased this card knowing about the driver issues that many people are experiencing. I have heard about black screens, crashes, games not rendering correctly and random down-clocking in certain games. I am glad to say that I do not experience any issues besides the down-clocking issue in 2 games (Rust, Minecraft). I paired this card with a Ryzen 5 3600 and a Dell SE2419HR 75Hz FreeSync monitor using HDMI.
Please note that this card is absolutely HUGE (it is the largest GPU I have ever seen) so please ensure that your case has enough space to fit this beast. Being so large, it has great cooling and much higher boost clocks compared to most other 5700 XT models. The fans stay very quiet and temperatures quite low while the card happily boosts over 2000 MHz all day long.
Although this card has teething issues, I am sure that after a few driver updates everything will be sorted out. This card is an absolutely beast and gets similar performance to the RTX 2070 SUPER in many games for a lower price. AMD's Radeon Software (although currently a bit buggy) is miles ahead of Nvidia's outdated Control Panel or the clunky GeForce Experience app. It allows you to customize everything about your graphics experience from changing advanced tuning settings (overclocking) to using very useful features such as Radeon ReLive (screen recording) and Radeon Image Sharpening.
Overall, I highly recommend this card. I hope that AMD works quickly on sorting out their drivers. - Ridiculous value! - TK, 25 February 2020
What an awesome card, rock-solid performance, the card exceeds the rated boost spec quite often boosting up to 2080mhz on the GPU clock which makes this one of the fastest 5700xt's out there which often helps this GPU hang with the 2070 super and sometimes even the 2080. The only criticism I have is that the card does get a bit toastier than the reviews suggest.
- Buy it - Brendan, 18 February 2020
Great card, especially for the money. Aesthetically great, build quality is great, cooling is decent and pushes pixels at a great frame rate. Very long, so make sure you have space.
- Good value - Richard, 16 February 2020
Card runs well, but good heavens this thing is long and heavy, need to get a GPU card support for the sag. runs quiet generally even under load. can get warm on silent mode so keeping it on performance mode from VBIOS switch is recommended. A good buy and comparable with Nitro+ in performance and cooling. good value.
- Exceeded my expectations - Clayton, 2 February 2020
This card is truely a beast, but i love the fact that my framrate never drops, with the bios switch enabled some games can go beyond 1440p to 4k on ultra
