| SPECIFICATIONS | |
| Brand | ASUS |
| Series | ROG Ally Series (2026) |
| Model | ROG Xbox Ally X20 Bundle RC74XA-TW004W |
| Processor | |
| Model | Ryzen AI Z2 Extreme |
| Chipset Manufacturer | AMD |
| Boost Clock | Up To 5.0GHz |
| Core Count | 8 Cores |
| Thread Count | 16 Threads |
| Cache | 24MB Cache |
| NPU | AMD XDNA NPU Up To 50 TOPS |
| Graphics | |
| Model | AMD Radeon Graphics |
| Display | |
| Size | 7.4" |
| Panel Type | OLED |
| Native Resolution | Full HD (1920x1080) |
| Refresh Rate | 120Hz |
| Colour Gamut | 100% DCI-P3 |
| Brightness | 600 Nits SDR / 1400 Nits HDR |
| Display Treatment | Anti-Reflection Coating, Gorilla Glass Victus, Gorilla Glass DXC |
| Variable Refresh Rates | AMD FreeSync Premium Pro |
| HDR Support | Dolby Vision HDR |
| Touch | Yes, 10-Point Multi-Touch |
| Storage | |
| Installed | 1x 1TB M.2 2280 PCIe 4.0 NVMe SSD |
| Supported | 1x UHS-I microSD Card Slot |
| Memory | |
| Total Installed | 24GB (On-Board) |
| Type | LPDDR5X |
| Configuration | Dual Channel |
| Maximum Capacity | No Slots For Memory Upgrades |
| Connectivity | |
| Ports | 1x USB4 Type-C Port With Thunderbolt 4 Compliance, DisplayPort 2.1 & Power Delivery 3.0 |
| 1x USB 3.2 Gen 2 Type-C Port With DisplayPort & Power Delivery | |
| 1x 3.5mm Combination Audio Jack | |
| 1x UHS-I microSD Card Reader | |
| Audio | |
| Speakers | Dual Speakers With Smart Amplifier Technology, Dolby Atmos |
| Microphones | Built-In Array Microphone With AI Noise-Canceling Technology |
| Headphone Support | Hi-Res Audio Certified |
| Networking | |
| Ethernet | N/A |
| WiFi | WiFi 6E (802.11ax) Triple-Band 2x2 |
| Bluetooth | Bluetooth 5.4 |
| Integrated Input Devices | |
| Gyroscope | Yes, 6-Axis IMU |
| Fingerprint Reader | Yes |
| Pointing Device | TMR Joysticks |
| Haptics | HD Haptics |
| Buttons | View Button |
| Menu Button | |
| A/B/X/Y Buttons | |
| Command Center Button | |
| Action Button | |
| L & R Impulse Triggers | |
| L & R Hall Effect Analog Triggers | |
| Transforming D-Pad | |
| 2x Assignable Grip Buttons | |
| General | |
| Security Platform | Microsoft Pluton Security Processor |
| Webcam | N/A |
| Operating System | Windows 11 Home |
| Battery | 80Wh 4-Cell Li-Ion |
| Power | 68W USB Type-C Power Adapter |
| Dimensions | 300 x 121 x 27.5 ~ 51.3mm (W x H x D) |
| Weight | 0.756kg |
| Colour | Translucent Black |
| Xbox Game Pass | 3 Months Xbox Game Pass Premium |
| Box Contents | ROG Xbox Ally X20 |
| ROG XREAL R1 Edition 20 | |
| 68W USB Type-C Power Adapter | |
| Documentation | |
| Warranty Information | |
| Warranty | 1 Year Warranty |
| Manufacturer's Site | Visit the manufacturer's website |
|---|---|
| Product Link | Visit the manufacturer's page for this product |
