| SPECIFICATIONS | |
| Brand | Creality |
| Series | Otter Series |
| Model | Otter Lite Basic |
| Scanning Mode | NIR(infrared binocular structured light) |
| Accuracy | 0.05mm@100mm [1] |
| 3D Resolution | 0.1-2mm |
| Scanning Speed | Up to 30fps |
| Min. scan volume | 20mm x 20mm x 20mm |
| Single Capture Range | Close range mode |
| 100mm*62mm@120mm | |
| 160mm*130mm@250mm | |
| Long range mode | |
| 352mm*254mm@300mm | |
| 788mm*509mm@600mm | |
| 1460mm*1017mm@1200mm | |
| Working distance | 120mm-1200mm |
| Colour Mapping | Yes |
| Alignment Mode | Marker / geometry / texture |
| Output Format | OBJ/STL/PLY |
| IMU | Yes |
| Marker Recognition Enhancement | 8 NIR LEDs |
| Colour Supplemental Light | 2 white LEDs |
| Laser Safety | Class I (eye safe) |
| Weight | Main unit: 300g |
| Lite bridge: 306g | |
| Size | 173mm x 39mm x 56mm |
| Calibration Board | High-precision glass calibration board |
| Wireless Scanning | Yes |
| Protocol | Wi-Fi 6, Backward compatibility |
| Wi-Fi Bands | 5GHz |
| Data Transfer Rate | Up to 30fps |
| Data Interface | Type-C/USB3.0/USB2.0 |
| Input Power | USB 3.0 5V 3A |
| WiFi 12V 2A | |
| Warranty Information | |
| Warranty | 1 Year Warranty |
| Manufacturer's Site | Visit the manufacturer's website |
|---|---|
| Product Link | Visit the manufacturer's page for this product |
