| SPECIFICATIONS | |
| Brand | Synology |
| Series | RackStation |
| Model | RS2423RP II |
| CPU | AMD Ryzen V1780B |
| CPU Quantity | 1 |
| CPU Cores | 4 |
| CPU Threads | 8 |
| CPU Architecture | 64-bit |
| CPU Frequency | 3.35 GHz (base) |
| 3.6 GHz (turbo) | |
| Hardware Encryption Engine | Yes |
| Memory | 8 GB DDR4 ECC UDIMM |
| Memory Module Pre-installed | 8 GB (8 GB ×1) |
| Total Memory Slots | 2 |
| Maximum Memory Capacity | 32 GB (16 GB ×2) |
| Storage | |
| Drive Bays | 12 |
| Max Drive Bays (with expansion) | 24 |
| Drive Type | 3.5" SATA HDD |
| 2.5" SATA SSD | |
| Hot Swappable Drive | Yes |
| External Ports | RJ-45 1GbE LAN ×2 |
| RJ-45 10GbE LAN ×1 | |
| USB 3.2 Gen 1 ×2 | |
| Expansion Port ×1 | |
| Expansion Port Type | Mini-SAS HD |
| PCIe | 1 × Gen3 x8 slot (x4 link) |
| Appearance | |
| Form Factor | 2U |
| Dimensions | 88 × 482 × 578 mm |
| Weight | 11.9 kg |
| Rack Support | 4-post 19" rack |
| Cooling | 60 mm fans ×3 |
| Fan Speed Modes | Full-Speed |
| Cool | |
| Quiet | |
| Easy Fan Replacement | Yes |
| Power Features | Power Recovery |
| Scheduled Power On/Off | |
| Wake on LAN/WAN | |
| Noise Level | 56.2 dB(A) |
| Power Supply | 550W |
| Redundant PSU | Yes |
| AC Input Voltage | 100 – 240V AC |
| Power Frequency | 50/60 Hz |
| Power Consumption | 114.86W (Access) |
| 42.33W (HDD Hibernation) | |
| Thermal Output | 392.18 BTU/hr (Access) |
| 144.53 BTU/hr (HDD Hibernation) | |
| Operating Temperature | 0°C to 35°C |
| Storage Temperature | -20°C to 60°C |
| Operating Humidity | 8% to 80% RH |
| Storage Humidity | 5% to 95% RH |
| Certifications | FCC |
| CE | |
| BSMI | |
| VCCI | |
| RCM | |
| UKCA | |
| EAC | |
| CCC | |
| KC | |
| BIS | |
| UL | |
| Warranty Information | |
| Warranty | 3 Year Warranty |
| Manufacturer's Site | Visit the manufacturer's website |
|---|---|
| Product Link | Visit the manufacturer's page for this product |
