| General |
| Brand | TP-Link |
| Series | Omada |
| Model | ER605W |
| Security |
| Access Control | Source/Destination IP Based Access Control |
| DNS Proxy | DNSSEC |
| DoH |
| DoT |
| Filtering | Web Group Filtering |
| URL Filtering |
| Web Security |
| ARP Inspection | Sending GARP Packets |
| ARP Scanning |
| IP-MAC Binding |
| Attack Defense | TCP/UDP/ICMP Flood Defense |
| Block TCP Scan (Stealth FIN/Xmas/Null) |
| Block Ping From WAN |
| Hardware Features |
| Interface | 1 Gigabit SFP WAN/LAN Port |
| 1 Gigabit WAN Port |
| 4 Gigabit LAN/WAN Ports |
| 1 USB3.0 (supports USB LTE dongle and USB Storage) |
| Button | Reset Button |
| Power Supply | 12VDC / 2A Power Adapter |
| Wi-Fi Frequency & Signal Rate | 2.4 GHz: 574 Mbps |
| 5 GHz: 2402 Mbps (HE160) |
| Flash | 128 MB NAND |
| DRAM | 512 MB DDR4 |
| LED | Power |
| SYS |
| 2.4G |
| 5G |
| WAN (1000/100/10M Link/Act) |
| WAN/LAN (1000/100/10M Link/Act) |
| Dimensions (W x D x H) | 226 mm x 131 mm x 35 mm (Antenna dimensions are not included) |
| Antenna | 2.4 GHz: 2x 3 dBi Dual-Band Detachable Antennas |
| 5 GHz: 3x 4.5 dBi Dual-Band Detachable Antennas |
| Mounting | Desktop/Wall-mounting |
| Max. Power Consumption | 22.7W (US, With USB 3.0 Connected) |
| Performance |
| GRE | Unencrypted: 624.2 Mbps |
| Encrypted: 301.5 Mbps |
| WireGuard VPN | 393.5 Mbps |
| Concurrent Session | 150,000 |
| New Sessions Per Second | 5,100 |
| NAT (Static IP) | 937.2 Mbps / 936.1 Mbps |
| NAT (DHCP) | 945.8 Mbps / 940.6 Mbps |
| NAT (PPPoE) | 942.9 Mbps / 942.9 Mbps |
| NAT (L2TP) | 837.4 Mbps / 881.5 Mbps |
| NAT (PPTP) | 803.0 Mbps / 910.5 Mbps |
| IPsec VPN Throughput (AES256) | ESP-SHA1-AES256: 175.5 Mbps |
| ESP-SHA256-AES256: 185.9 Mbps |
| ESP-SHA384-AES256: 30.9 Mbps |
| ESP-SHA512-AES256: 30.7 Mbps |
| IPsec VPN Throughput | ESP-SHA1-AES256: 646.9 Mbps |
| ESP-SHA256-AES256: 642.8 Mbps |
| ESP-SHA384-AES256: 648.9 Mbps |
| ESP-SHA512-AES256: 658.4 Mbps |
| OpenVPN | 129.3 Mbps |
| L2TP VPN Throughput | Unencrypted: 1034.0 Mbps |
| Encrypted: 570.0 Mbps |
| PPTP VPN Throughput | Unencrypted: 1165.0 Mbps |
| Encrypted: 209.0 Mbps |
| SSL VPN Throughput | 126.7 Mbps |
| 66 Byte Packet Forwarding Rate | 1,453,489 pps / 1,453,488 pps |
| 1,518 Byte Packet Forwarding Rate | 81,274 pps / 91,275 pps |
| Wireless Features |
| Advanced Features | Seamless Roaming |
| Mesh (with EAP that supports Mesh) |
| OFDMA |
| Beamforming |
| MU-MIMO |
| Wireless Encryption: WPA/WPA2/WPA3 Personal |
| WPA/WPA2/WPA3 Enterprise |
| Guest Network | Support |
| Basic Network Functions |
| WAN Connection Type | Static IP |
| Dynamic IP |
| PPPoE (supports MRU Configuration) |
| PPTP |
| L2TP |
| MAC Clone | Modify WAN Address |
| DHCP | DHCP Server |
| DHCPv6 PD Server (only in Standalone Mode) |
| DHCP Options Customization |
| DHCP Address Reservation |
| Multi-IP Interfaces |
| Multi-Net DHCP |
| Stateful ACL | Supported |
| Quality of Service | Supported |
| Bridge VLAN | Supported |
| mDNS Repeater | Supported |
| IPv6 | StaticIP |
| SLAAC |
| DHCPv6 |
| PPPoE |
| 6to4Tunnel |
| PassThrough |
| Non-Address Mode |
| VLAN | 802.1Q VLAN |
| IPTV | IGMP v2/v3 Proxy |
| Custom Mode |
| Bridge Mode |
| Advanced Network Functions |
| Access Control | IP/Port/Protocol/Domain Name Filtering |
| Advanced Routing | Static Routing |
| Policy Routing |
| RIP |
| OSPF |
| Bandwidth Control | IP-Based Bandwidth Control |
| Load Balance | Intelligent Load Balance |
| Application Optimized Routing |
| Link Backup (Timing, Failover) |
| Online Detection |
| NAT | One-to-One NAT |
| Multi-Net NAT |
| Virtual Server |
| Port Triggering |
| NAT-DMZ |
| FTP/H.323/SIP/IPSec/PPTP ALG |
| UPnP |
| Session Limit | IP-Based Session Limit |
| VPN Features |
| GRE | Only in Standalone Mode |
| SSL VPN | 50 Tunnels |
| IPsec VPN | 100 IPSec VPN Tunnels |
| LAN-to-LAN |
| Client-to-LAN |
| Main |
| Aggressive Negotiation Mode |
| DES |
| 3DES |
| AES128 |
| AES192 |
| AES256 Encryption Algorithm |
| IPsec Failover |
| IKE v1/v2 |
| MD5 |
| SHA1 |
| SHA2-384 and SHA2-512 Authentication Algorithm |
| NAT Traversal (NAT-T) |
| Dead Peer Detection (DPD) |
| Perfect Forward Secrecy (PFS) |
| PPTP VPN | PPTP VPN Server |
| PPTP VPN Client (10) |
| 50 Tunnels |
| PPTP with MPPE Encryption |
| L2TP VPN | L2TP VPN Server |
| L2TP VPN Client (10) |
| 50 Tunnels |
| L2TP over IPSec |
| OpenVPN | OpenVPN Server |
| OpenVPN Client (5) |
| 55 OpenVPN Tunnels |
| "Certificate + Account" Mode |
| Full Mode |
| WireGuard VPN | Supported |
| Authentication |
| Web Authentication | No Authentication |
| Simple Password |
| Hotspot (Local User / Voucher / SMS / Radius) |
| External Radius Server |
| External Portal Server |
| LDAP |
| Management |
| Omada App | Yes |
| Centralized Management | Omada Cloud-Based Controller |
| Omada Hardware Controller (OC300) |
| Omada Hardware Controller (OC200) |
| Omada Software Controller |
| Cloud Access | Yes |
| Service | Dynamic DNS (Dyndns, No-IP, Peanuthull, Comexe, DDNS Customization) |
| Maintenance | Web Management Interface |
| Remote Management |
| Export & Import Configuration |
| SNMP v1/v2c/v3 |
| Diagnostics (Ping & Traceroute) |
| NTP Synchronize |
| Port Mirroring |
| CLI (only in Standalone Mode) |
| Syslog Support |
| Zero-Touch Provisioning | Yes (Require the use of Omada Cloud-Based Controller) |
| Additional Management Features | Automatic Device Discovery |
| Intelligent Network Monitoring |
| Abnormal Event Warnings |
| Unified Configuration |
| Reboot Schedule |
| Captive Portal Configuration |
| Other Information |
| Network Services Enabled by Default | Web Server (Port: 80/443, Protocol: TCP) |
| TDP Server (Port: 20003, Protocol: UDP) |
| DHCP Server (Port: 67, Protocol: UDP) |
| DNS (Port: 53, Protocol: TCP/UDP) |
| Certifications | CE |
| FCC |
| RoHS |
| Package Contents | ER605W |
| Power Adapter |
| Quick Installation Guide |
| System Requirements | Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7/8/8.1/10/11 |
| MAC OS |
| NetWare |
| UNIX or Linux |
| Environment | Operating Temperature: 0 °C to 40 °C (32 °F to 104 °F) |
| Storage Temperature: -40 °C to 70 °C (-40 °F to 158 °F) |
| Operating Humidity: 10% to 90% non-condensing |
| Storage Humidity: 5% to 90% non-condensing |
| Warranty Information |
| Warranty | 2 Year Warranty |
