| SPECIFICATIONS |
| Brand | TP-Link |
| Series | Omada |
| Model | ER7412-M2 |
| Product Number | ER7412-M2 |
| Product Type | Omada Multi-Gigabit VPN Router |
| Colour | Black |
| Hardware |
| Processor | Quad-core ARMv8 Cortex-A53 processor at 2.0 GHz |
| Network Interfaces | 2× 2.5G RJ45 WAN/LAN ports; 2× Gigabit SFP WAN/LAN ports; 8× Gigabit RJ45 WAN/LAN ports; 1× RJ45 console port; 1× USB 3.0 port |
| USB Functionality | Supports USB storage and LTE backup with a compatible LTE dongle |
| Standards and Protocols | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x and IEEE 802.1Q; TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPsec, PPTP, L2TP, OpenVPN, WireGuard VPN, GRE VPN and SNMP |
| Network Media | 10BASE-T: UTP Category 3, 4 or 5 up to 100 m; 100BASE-TX: UTP Category 5 or 5e up to 100 m; 1000BASE-T: UTP Category 5, 5e or 6 up to 100 m; 2500BASE-T: UTP Category 5e or 6 up to 100 m |
| Button | Reset button |
| Power Supply | 100–240 V AC, 50/60 Hz |
| Flash Memory | 128 MB NAND |
| System Memory | 1 GB DDR4 |
| Product Weight | 1.168 kg product weight |
| Dimensions | 294 × 180 × 44 mm |
| Protection | 4 kV surge protection |
| Mounting | Desktop or rack mounting |
| Maximum Power Consumption | 18.5 W with USB 3.0 connected |
| Performance |
| Concurrent Sessions | 1,000,000 |
| New Sessions per Second | 7,000 |
| Static IP NAT Throughput | 2,345.71 Mbps upload / 2,351.22 Mbps download |
| VPN Performance | IPsec ESP-SHA256-AES256: 1,133.1 Mbps; WireGuard: 771.2 Mbps; OpenVPN UDP: 266.2 Mbps; SSL: 263.1 Mbps |
| Routing and Network |
| WAN Connection Types | Dynamic IP, Static IP, PPPoE, PPTP and L2TP |
| IPv6 Support | Static IP, SLAAC, DHCPv6, PPPoE, 6to4 tunnel, pass-through and non-address mode |
| VLAN | 802.1Q VLAN |
| Advanced Routing | Static routing and policy routing; RIP and OSPF are supported in Standalone Mode |
| Load Balancing and Link Backup | Intelligent load balancing, application-optimized routing, timed link backup, failover link backup and online detection |
| NAT Features | One-to-one NAT, Multi-Net NAT, virtual server, port triggering, NAT-DMZ, FTP/H.323/SIP/IPsec/PPTP ALG and UPnP |
| VPN and Security |
| VPN Protocols | SSL, IPsec, WireGuard, PPTP, L2TP and OpenVPN; GRE is supported in Standalone Mode |
| Firewall and Threat Protection | DoS/DDoS protection, IP/MAC/URL filtering, deep packet inspection and intrusion detection/prevention |
| Management |
| Centralized Management | Omada centralized cloud management through the web or Omada app; requires an Omada Controller |
| Zero-Touch Provisioning | Supported with the Omada cloud-based controller |
| Packaging |
| Package Contents | ER7412-M2, power cord, Quick Installation Guide, rackmount kit and RJ45 console cord |
| System and Environment |
| System Requirements | Microsoft Windows 98SE, NT, 2000, XP, Vista, 7, 8, 8.1, 10 or 11; macOS, NetWare, UNIX or Linux |
| Operating Environment | 0°C to 45°C; 10% to 90% RH, non-condensing |
| Storage Environment | -40°C to 70°C; 5% to 90% RH, non-condensing |
| Certification | CE, FCC and RoHS |
| Warranty Information |
| Warranty | 2 Year Warranty |
