| General | |
| Brand | TP-Link |
| Series | Omada |
| Model | ES220GMP |
| Hardware Features | |
| Interface | 16× 10/100/1000 Mbps PoE+ RJ45 Ports |
| 2× 10/100/1000 Mbps RJ45 Ports | |
| 2× Gigabit SFP Slots | |
| Auto-Negotiation/Auto MDI/MDIX | |
| Fan Quantity | 2 |
| Installation | Rackmountable |
| Physical Security Lock | Yes |
| Power Supply | 100–240V AC, 50/60Hz |
| PoE Standard | 802.3af PoE |
| 802.3at PoE+ | |
| PoE Port Quantity | 16 |
| Total PoE Budget | 250 W |
| Max PoE Per Port | 30 W |
| PoE Features | Fast PoE |
| Perpetual PoE | |
| PoE Auto Recovery | |
| Up To 250m PoE Transmission | |
| Dimensions (W x D x H) | 440 mm × 180 mm × 44 mm |
| Surge Protection | ±6kV |
| Max. Power Consumption | 289.7 W (110V/60Hz) (with 250 W PD connected) |
| Max. Heat Dissipation | 984.88 BTU/hr (110 V/60 Hz) (with 250 W PD connected) |
| Performance | |
| Packet Buffer Memory | 4 Mbit |
| Jumbo Frame | 15 KB |
| Switching Capacity | 40 Gbps |
| Packet Forwarding Rate | 29.76 Mpps |
| MAC Address Table | 8K |
| Software Features | |
| Quality Of Service | Port-based QoS |
| 802.1p QoS | |
| DSCP QoS | |
| Priority Queues | 8 |
| Priority Schedule Mode | WRR (Weighted Round Robin) |
| Queue Weight Config | Yes |
| Bandwidth Control | Port-Based Rating Limit |
| Storm Control | Multiple Control Modes (kbps/pps) |
| Broadcast Control | |
| Multicast Control | |
| Unknown-Unicast Control | |
| L2 Features | Static Link Aggregation |
| Loop Prevention | |
| Loopback Detection | |
| 802.3x Flow Control | |
| Mirroring | Port Mirroring (One-to-One, Many-to-One, Ingress/Egress/Both) |
| Port Statistics | Port Mirror Status |
| Traffic Statistics | |
| LLDP Standard | 802.1ab |
| L2 Multicast | IGMP Snooping (IGMP v1/v2/v3 Snooping, Fast Leave) |
| VLAN | MTU VLAN |
| Port-Based VLAN | |
| 802.1Q Tag VLAN | |
| Max VLAN Groups | 32 |
| VID Range | 4K |
| Transmission Method | Store-And-Forward |
| Management | |
| Omada App Support | Yes |
| Centralized Management Compatibility | Omada Cloud-Based Controller |
| Omada Hardware Controller | |
| Omada Software Controller | |
| Cloud Access | Yes |
| Zero-Touch Provisioning Support | Yes |
| Additional Management Features | Web-based GUI |
| DHCP Client | |
| Cable Diagnostics | |
| Automatic Device Discovery | |
| Batch Configuration | |
| Batch Firmware Upgrading | |
| Unified Configuration | |
| Others | |
| Certification | FCC |
| CE | |
| RoHS | |
| Package Contents | ES220GMP |
| Power Cord | |
| Mounting Brackets | |
| Rubber Feet | |
| Screws | |
| Installation Guide | |
| Operating Temperature | -5℃~50℃ (23℉~122℉) |
| Storage Temperature | -40℃~70℃ (-40℉~158℉) |
| Operating Humidity | 10%~90% Non-Condensing |
| Storage Humidity | 5%~90% Non-Condensing |
| Warranty Information | |
| Warranty | 2 Year Warranty |
| Manufacturer's Site | Visit the manufacturer's website |
|---|---|
| Product Link | Visit the manufacturer's page for this product |
