| SPECIFICATIONS |
| Brand | Ubiquiti |
| Series | UniFi Gateway Series |
| Model | Dream Machine Pro Max Cloud Gateway (UDM-PRO-MAX) |
| Dimensions | 442.4 x 43.7 x 285.6 mm |
| Managed UniFi Devices | 200+ |
| Managed Cameras | (50) HD |
| (25) 2K |
| (15) 4K |
| Managed Access Hubs 150 |
| Simultaneous Users Connected | 2,000+ |
| Max. WAN Port Count | 8 |
| Ports | 1x 10 Gigabit Ethernet SFP WAN Port |
| 1x 10 Gigabit Ethernet SFP LAN Port |
| 1x 2.5 Gigabit Ethernet RJ-45 WAN Port |
| 8x Gigabit Ethernet RJ-45 LAN Ports |
| IDS/IPS Throughput | 5 Gbps |
| Form Factor | Rack mount (1U) |
| Redundancy | Shadow Mode (VRRP) Gateway Failover |
| DC Power Backup |
| Security |
| Supported Security Features | Stateful Firewall |
| Application-Aware Layer 7 Firewall |
| DPI & Traffic Identification |
| Zone-Based Firewall Advanced Filtering (Regions, Domains, Apps) |
| Content Filtering |
| Intrusion Prevention (IPS/IDS) |
| Ad Blocking |
| 55,000 IDS/IPS Signatures with CyberSecure (Subscription, Sold Separately) |
| VLAN/Subnet-based Traffic Segmentation |
| VPN & SD-WAN |
| License-Free SD-WAN | Support Included |
| Site-to-Site VPN | Site Magic |
| IPsec |
| OpenVPN |
| VPN Server | Identity Endpoint One-Click VPN |
| Teleport Zero-Configuration VPN |
| WireGuard |
| OpenVPN |
| L2TP |
| VPN Client | OpenVPN |
| WireGuard |
| Networking |
| Supported Networking Features | Multi-WAN Load Balancing |
| Shadow Mode (VRRP) High Availability |
| LACP Port Aggregation |
| Advanced QoS |
| Multicast DNS (mDNS) |
| Advanced NAT (SNAT / DNAT / Masquerade / NAT Pooling / 1-to-1 NAT) |
| Integrated RADIUS Server |
| RADIUS over TLS (RadSec) |
| Additional Internet Failover with UniFi LTE Backup |
| Internet Quality and Outage Reporting |
| 4K MAC Address Table Size |
| Policy-based WAN and VPN Routing |
| Customizable DHCP Server |
| IPv6 ISP Support |
| IGMP Proxy |
| Virtual Network Override |
| All Traffic Flows |
| Dynamic Routing | OSPF |
| BGP |
| Hardware |
| NVR Storage | (2) 3.5" NVR HDD bays |
| Built-in 128 GB SSD for Faster Experience |
| Power Consumption | 60W (Max) |
| Power Source | Universal AC input, 100—240V AC, 2A Max., 50/60 Hz |
| USP-RPS DC input, 11.5V DC, 8.7A |
| Power Supply | AC/DC, internal, 100W |
| Supported Voltage Range | 100—240V AC |
| Heat Dissipation | 205 BTU/hr |
| Processor | Quad-core ARM Cortex-A57 at 2.0 GHz |
| System Memory | 8 GB |
| On-board Storage | 32 GB eMMC (Firmware, OS) |
| 128 GB SSD (Integrated, for NVR) |
| Weight | 4.7 kg |
| Enclosure Material | Aluminium CNC, SGCC steel |
| Mount Material | SGCC steel |
| LCM Display | 1.3" touchscreen |
| Management | Ethernet |
| Bluetooth |
| General |
| ESD/EMP Protection | Air: ± 15kV, contact: ± 8kV |
| Ambient Operating Temperature | -10 to 40° C (14 to 104° F) |
| Ambient Operating Humidity | 5 to 95% noncondensing |
| NDAA Compliant | Yes, compliant. |
| Certifications | CE, FCC, IC, Anatel: 06369-24-08356, SRRC |
| Warranty Information |
| Warranty | 1 Year Warranty |
