| SPECIFICATIONS | |
| Brand | TP-Link |
| Series | Omada |
| Model | ES210GMP |
| Port Configuration | 10-Port Gigabit |
| 8-Port PoE+ | |
| 1× 10/100/1000Mbps RJ45 Port | |
| 8× 10/100/1000Mbps PoE+ RJ45 Ports | |
| 1× Gigabit SFP/RJ45 Combo Port | |
| Network Standards | 802.3af PoE |
| 802.3at PoE+ | |
| Auto-Negotiation | |
| Auto MDI/MDIX | |
| PoE Features | 123W PoE Budget |
| Up To 30W Per Port | |
| Fast PoE | |
| Perpetual PoE | |
| PoE Auto Recovery | |
| Up To 250m PoE Transmission Distance | |
| Performance | 20 Gbps Switching Capacity |
| 14.88 Mpps Packet Forwarding Rate | |
| 8K MAC Address Table | |
| 4 Mbit Packet Buffer Memory | |
| 15 KB Jumbo Frame | |
| Switching Features | Store-And-Forward |
| QoS | Port-Based QoS |
| 802.1p QoS | |
| DSCP QoS | |
| 8 Priority Queues | |
| WRR (Weighted Round Robin) | |
| Queue Weight Config | |
| Bandwidth Control | |
| Port-Based Rating Limit | |
| Storm Control | |
| Broadcast Control | |
| Multicast Control | |
| Unknown-Unicast Control | |
| Layer 2 Features | Static Link Aggregation |
| Loop Prevention | |
| Loopback Detection | |
| 802.3x Flow Control | |
| Port Mirroring | |
| One-to-One Mirroring | |
| Many-to-One Mirroring | |
| Ingress/Egress/Both Mirroring | |
| Port Statistics | |
| Port Mirror Status | |
| Traffic Statistics | |
| 802.1ab LLDP | |
| Multicast Features | IGMP v1 Snooping |
| IGMP v2 Snooping | |
| IGMP v3 Snooping | |
| Fast Leave | |
| VLAN Features | MTU VLAN |
| Port-Based VLAN | |
| 802.1Q Tag VLAN | |
| Max 32 VLAN Groups | |
| 4K VID | |
| Management | Centralized Cloud Management |
| Omada App Support | |
| Omada Cloud-Based Controller | |
| Omada Hardware Controller | |
| Omada Software Controller | |
| Cloud Access | |
| Zero-Touch Provisioning | |
| Web-Based GUI | |
| DHCP Client | |
| Cable Diagnostics | |
| Automatic Device Discovery | |
| Batch Configuration | |
| Batch Firmware Upgrading | |
| Unified Configuration | |
| Physical Features | Fanless Design |
| Metal Casing | |
| Desktop Mount | |
| Wall Mount | |
| Physical Security Lock | |
| Power | DC Power Adapter |
| 53.5V DC / 2.43A | |
| Surge Protection | ±6kV |
| Dimensions | 209 × 126 × 26 mm |
| Certification | FCC |
| CE | |
| RoHS | |
| Package Contents | ES210GMP |
| Power Adapter | |
| Installation Guide | |
| Rubber Feet | |
| Environmental | Operating Temperature: 0°C To 40°C |
| Storage Temperature: -40°C To 70°C | |
| Operating Humidity: 10% To 90% Non-Condensing | |
| Storage Humidity: 5% To 90% Non-Condensing | |
| Warranty Information | |
| Warranty | 2 Year Warranty |
| Manufacturer's Site | Visit the manufacturer's website |
|---|---|
| Product Link | Visit the manufacturer's page for this product |
