Features Product Description
Additional Information
Reviews (0)
| SPECIFICATIONS | |
| Brand | Gigabyte |
| Series | WINDFORCE OC SFF Series |
| Model | GeForce RTX 5080 WINDFORCE OC SFF 16G (GV-N5080WF3OC-16GD) |
| Chipset | |
| GPU | GeForce RTX 5080 |
| Chipset Manufacturer | NVIDIA |
| Interface | PCIe 5.0 x16 |
| Base Clock | 2300 MHz |
| Boost Clock | Up to 2670 MHz |
| CUDA Cores | 10,752 Cores |
| GPU Architecture | NVIDIA Blackwell |
| Memory | |
| Effective Memory Clock | 30Gbps |
| Memory Size | 16GB |
| Memory Interface | 256-bit |
| Memory Type | GDDR7 |
| 3D API | |
| DirectX | Microsoft DirectX 12.1 Ultimate |
| OpenGL | OpenGL 4.6 |
| Vulkan | Vulkan 1.4 API |
| Connectivity | |
| Ports | 1x HDMI 2.1b |
| 3x DisplayPort 2.1b | |
| HDCP Support | Yes, 2.3 |
| Multi-Monitor Support | Up to 4 |
| Maximum Digital Resolution | 7680 x 4320 |
| VR Ready | Yes |
| General | |
| SLI Support | N/A |
| Features | WINDFORCE cooling system |
| Hawk fan | |
| Server-grade thermal conductive gel | |
| Dual BIOS (Performance / Silent) | |
| Reinforced structure | |
| Versatile GPU Holder | |
| NVIDIA SFF-ready | |
| 4th Gen Ray Tracing Cores | |
| 5th Gen Tensor Cores | |
| PCI Express Gen 5 | |
| Real-Time Ray Tracing Technology | |
| NVIDIA DLSS 4.0 with Frame Generation and Frame Warp | |
| NVIDIA GeForce Game Ready & Studio Drivers | |
| NVIDIA G-Sync Premium | |
| NVIDIA Reflex 2 | |
| NVIDIA Broadcast | |
| NVIDIA AV1 Encoder | |
| NVIDIA Omniverse 3D Design | |
| NVIDIA Canvas | |
| NVIDIA GPU Boost | |
| NVIDIA Encoder, 9th Generation | |
| NVIDIA Decoder, 6th Generation | |
| Power Requirements | |
| Recommended Power Supply | 850W |
| Power Connector | 1x 16-Pin 12VHPWR Connector |
| Physical Aspects | |
| Form Factor | ATX |
| Slot Width | 50mm |
| Dimensions | 304mm x 126mm x 50mm |
| RGB | Yes, Supports GIGABYTE CONTROL CENTER. |
| Boxed Accessories | 1. VGA manual |
| 2. 1x 12V-2x6 to 3x PCIe 8pin adapter | |
| 3. Versatile VGA holder | |
| 4. Versatile VGA holder manual | |
| Warranty Information | |
| Warranty | 3 Year Warranty |
| Manufacturer's Site | Visit the manufacturer's website |
|---|---|
| Product Link | Visit the manufacturer's page for this product |
