| SPECIFICATIONS | |
| Brand | Mecer |
| Series | Innova |
| Model | ME-6000-WPTV |
| Dimensions | 248mm x 500mm x 616mm |
| Weight | 58.9Kg |
| Power | |
| Apparent Power(KVA) | 6 KVA |
| Active power(KW) | 5.4 KW |
| Mains | |
| Voltage Range | 120Vac - 275Vac (Phase to Phase) |
| Current | 32.1A max |
| Frequency range | 40Hz - 70Hz |
| Power factor | 0.99 |
| Output | |
| Rating Voltage | 230Vac(±1%) |
| Rating Current | 27A |
| Frequency Range | 50Hz x (1±1%) |
| Power factor | 0.9 |
| Output Overload | 105%-125%, load transfer to bypass mode after 10 min (0-30℃) or 1min(30-40℃) |
| 125%-150%,load transfer to bypass mode after 30s | |
| Over 150%, load transfer to bypass after 0.5s | |
| Load Crest Ratio | 3:1(Max) |
| THD | <2%( 100% Line load) |
| Enviromental & Safety | |
| EMC Standard | EN IEC 62040-2:2018 |
| EN 62040-2:2006 | |
| IEC 62040-2:2016 | |
| Safety Standard | EN62040-1:2008+A1:2013 |
| Operating Temperature | 0°C - 40°C |
| Storage Temperature | -25°C 55°C |
| Relative humidity | 20% - 90% |
| Altitude | < 1000m |
| Warranty Information | |
| Warranty | 1 Year Warranty With 6 Month Battery Warranty |
| Manufacturer's Site | Visit the manufacturer's website |
|---|---|
| Product Link | No |
