| SPECIFICATIONS | |
| Brand | Antec |
| Series | AX Elite Series |
| Model | AX85 ARGB Black (0-761345-10173-8) |
| Physical Details | |
| Colour | Black |
| Materials | Steel |
| Plastic | |
| Tempered Glass | |
| Side Panel | Clear Tempered Glass Side Panel |
| Front I/O | 2x Front-Panel USB 5Gbps Type-A Ports |
| 1x 3.5mm Combination Audio Jack | |
| Motherboard Support | Supports ATX, Micro-ATX, Mini-ITX Motherboards |
| Expansion Slots | 7x PCI Slots |
| Drive Bays | 2x 2.5" HDD/SSD Drive Bays |
| 2x 2.5"/3.5" Combo Drive Bay (Removable) | |
| PSU Support | ATX |
| Dimensions | 393 x 205 x 485mm (D x W x H) |
| Weight | 6.3kg |
| Pre-Installed Fans | |
| Front | 3x Antec 120mm ARGB PWM Fans (Intake) |
| Top | N/A |
| Rear | 1x Antec 120mm ARGB PWM Fan (Exhaust) |
| Fan Support | |
| Front | 3x 120mm or 2x 140mm Fans |
| Top | 2x 120mmor 2x 140mm Fans |
| Rear | 1x 120mm Fan |
| PSU Shroud | 2x 120mm Fans |
| Radiator Support | |
| Front | 120 / 140 / 240 / 280 / 360mm Radiator |
| Top | 120 / 240mm Radiator |
| Rear | 120mm Radiator |
| Clearance | |
| CPU Cooler Height Limitation | 160mm |
| GPU Length Limitation | Up to 340mm (with front fans) |
| Up to 370mm (with front fans) | |
| Cable Management | Yes, 23mm depth |
| PSU Length Limit | Up to 200mm (with drive cage installed) |
| Up to 370mm (with drive cage removed) | |
| General | |
| Dust Filters | Yes, Front & Bottom dust filters |
| Chassis Lighting | 3-Pin 5V Daisy-chained ARGB fans with a proprietary connector support all motherboards and controller software |
| Supports MSI Mystic Light, ASUS AURA, Gigabyte RGB Fusion, ASRock Polychrome, Razer Chroma | |
| Warranty Information | |
| Warranty | 1 Year Warranty |
| Manufacturer's Site | Visit the manufacturer's website |
|---|---|
| Product Link | Visit the manufacturer's page for this product |
- A little tight, a little sharp, but it works well - Warren, 5 June 2025
A bit smaller internally than I'd expected, there is enough channeling for cables, but a normal non-modular power supply is going to leave you with a really messy side.
Fans are nice and quiet and give a decent amount of light :-) son loves it, the build quality is overall decent, with some sharp edges in places but far better than other cases are in this category and price range.
Air flow is sufficient for the case, would 4 more fans benefit? Possibly though it would depend on the rest of the stuff in the case. Glass panel being a slide off like the other panel was a little odd, but it does seem to be sturdy, but do prefer how Phantek do it.
Will I get another Antec? Actually yeah might just.
