| SPECIFICATIONS | |
| Brand | ASRock |
| Series | Arc Graphics Series |
| Model | Arc B580 Challenger OC 12GB (B580 CL 12GO) |
| Chipset | |
| GPU | Arc B580 |
| Chipset Manufacturer | Intel |
| Interface | PCIe 4.0 x8 (x16 Physical) |
| Graphics Clock | Up to 2740MHz |
| Xe-Cores | 20 Xe2 Cores |
| Render Slices | 5x slices |
| Ray Tracing Units | 20x second-generation RT units |
| Intel Xe Matrix Extensions (Intel XMX) Engines | 160 engines |
| Xe Vector Engines | 160 engines |
| Lithography Type | TSMC N5 Process |
| GPU Architecture | Intel Battlemage |
| Memory | |
| Effective Memory Clock | 19 Gbps |
| Memory Bandwidth | 465 GB/s |
| Memory Size | 12GB |
| Memory Interface | 192-bit |
| Memory Type | GDDR6 |
| Supported Technologies | |
| DirectX | DirectX 12 Ultimate |
| OpenGL | 4.6 |
| Vulkan | 1.3 |
| OpenCL | 3.0 |
| Ray Tracing | Yes |
| Variable Rate Shading (VRS) | Yes |
| Adaptive Sync | Yes |
| Multi-Format Codec Engines | 2 |
| Intel Extension for PyTorch* (IPEX) | Yes, supported (software features may vary) |
| Connectivity | |
| Ports | 1x DisplayPort 2.1 port (UHBR13.5) |
| 2x DisplayPort 2.1 ports (UHBR10) | |
| 1x HDMI 2.1a port | |
| Multi-Monitor Support | 4 |
| Maximum Digital Resolution | 7680 x 4320@60Hz |
| General | |
| Features | H.264 Hardware Encode/Decode |
| H.265 (HEVC) Hardware Encode/Decode | |
| AV1 Encode/Decode | |
| VP9 Bitstream & Decoding | |
| Intel Deep Link Hyper Compute | |
| Intel Deep Link Hyper Encode | |
| Intel Deep Link Stream Assist | |
| Intel Xe Super Sampling (XeSS) | |
| Intel Xe HPG Microarchitecture | |
| Power Requirements | |
| Recommended Power Supply | 650W |
| TBP | 220W |
| Power Connector | 1x 8-Pin PCI PEG Connector |
| Form Factor | ATX |
| Slot Width | Dual-slot |
| Dimensions | 249 x 132 x 41mm (L x W x H) |
| Weight | 0.720kg |
| Unique Features | Dual Fan Design |
| Stylish Metal Backplate | |
| Striped Axial Fan | |
| LED Indicator | |
| 0dB Silent Cooling | |
| Super Alloy Graphics Card | |
| Warranty Information | |
| Warranty | 3 Year Warranty |
| Manufacturer's Site | Visit the manufacturer's website |
|---|---|
| Product Link | Visit the manufacturer's page for this product |
- B580 bang for buck. - Johan, 21 May 2025
This card is a budget gaming gem! Running ED at 4k no problems. It was time to retire the RX580 and this one fit the budget. Very happy with it given the price vs performance. Getting the odd BSD though but that is due to installing it into a existing windows 10 install and removing the old drivers. Do a fresh Win install.
- Insane price-performance ratio - WB, 18 May 2025
Seriously, if you're still pondering whether or not to pull the trigger on this card, just do it already. Neither of the bigger brands have a card at this price point with these specs which perform this well at 1080p and 1440p. Driver software is well put together with auto updates and I've yet to run into compatibility issues with a game. Updates are regularly released as well. Well done to Intel for creating this beast of an underdog. I'm extremely satisfied with my purchase and can recommend this card without hesitation, and happy that there is some additional competition being introduced to the GPU market - about damned time too!!!
- Best Buy Ever - Eon , 10 May 2025
I recently upgraded to the ASRock Arc A580 Challenger OC 12GB graphics card, and it’s been a fantastic addition to my setup. Gaming at 1080p is smooth, even with demanding titles like Cyberpunk 2077 and Starfield, thanks to its 12GB of GDDR6 memory and ray tracing support. The card stays cool and quiet, with temperatures rarely exceeding 65°C under load. Installation was easy, and it looks clean in my build. Overall, it offers great value for gamers looking for solid performance without breaking the bank. I’m really happy with this upgrade!
- From 1050Ti to this BEAST!!! - Okker, 2 April 2025
I was worried that I have to update my BIOS, for ReBar support. However I bought my B550M-board from WoortWare 2-3 years back, and they did it for me before delivery. So this was very easy to install and setup myself. This card is great, it performs way better than I expected from an Arc card. Definitely worth the buy. WootWare still my recommended place to go for hardware.
- Working Great - Robin, 17 March 2025
Previous XFX AMD RX570 packed up after 7 years. System: R7 2700 cpu, MSI x470 gaming pro. update bios ,enabled rebar and voila its working. For me massive upgrade to games and production apps. Very happy , now for cpu and MB upgrade. Never had a problem with Wootware sofar, always helpful and fast delivery.
- It works! - Robin, 11 March 2025
I had a XFX RX 570 AMD card, my system is an AMD Ryzen 7 2700, MSI x470 gaming pro. AMD card packed up after 7 years of good use. Was worried this card won't work but it was in line with my budget. I had no problems with install and running it, just updated BIOS to latest, enabled REBAR. Using it couple of days now and got massive increase in fps on my games even on gen 3 components. Very happy indeed. Delivery and service excellent from the team. Now to upgrade the MB and CPU
- Awesome! - Antonie, 20 February 2025
Had a couple of issues with setup, after resetting the motherboard and reconfiguring the BIOS from scratch everything detected and worked fine with no issues. It was not detecting REBAR enabled, etc.
- Bang for Buck! - Evert, 18 February 2025
Awesome card. probably the best rand to performance card available in SA at the moment, especially for lower resolution gaming (e.g., 1080P & 1440P). Solid build quality from ASRock. If you're looking to overclock it some more, rather go with the Steel Legend. Lastly, a shout out to Wootware for delivering the card to me in Gauteng at record pace!
