ASUS ROG Strix X870E-E Gaming WIFI AMD X870E Ryzen Socket AM5 ATX Desktop Motherboard

More Views

Please note:
Images are for illustrative purposes only.

ASUS ROG Strix X870E-E Gaming WIFI AMD X870E Ryzen Socket AM5 ATX Desktop Motherboard

Product ID: 48133

In stock with Wootware

Lead time before dispatch; 1 - 2 business days
Limited stock remaining

Be the first to review this product

- ATX Form Factor
- AMD X870E Chipset
- Socket AM5
- AMD Ryzen 9000 & 8000 & 7000 Series CPUs Supported
- 4x DDR5 DIMM Slots, Supports Up to 192GB
- Supports up to DDR5-8000MHz+(OC)
- 1x PCIe 5.0 x16 slots (supports x16 mode)
- 1x PCIe 4.0 x16 slot (supports x4 mode)
- 5x M.2 Slots and 4x SATA 6Gb/s Ports
- 2x USB 4 (40Gbps) Type-C Ports
- 1x USB 20Gbps Type-C port (Up to 30W PD Fast-charge)
- 9x USB 10Gbps Type-A Ports, 1x USB 10Gbps Type-C Ports
- 1x HDMI Port, 1 x Wi-Fi Module
- 1x Realtek 5Gb Ethernet, 2x Gold-plated audio jacks
- 1x Optical S/PDIF out port, 1x BIOS FlashBack Button
- 1x Clear CMOS Button
- 802.11be 2x2 Tri-Band WiFi 7
- Bluetooth v5.4
- 18(110A)+ 2(110A)+ 2 Power Stages
- Dual ProCool II Power Connectors
- M.2 Combo-Sink, 3x M.2 Heatsinks
- SupremeFX ALC4080 Codec
- Savitech SV3H712 AMP
- 3 Year Warranty

252 Products

Please note: pricing visible is already subject to a 2% discount applicable only to EFT payments.

R14,199.00

R10,499.00

Save: R 3,700!

Qty:

Add to Wishlist

Product Description
Additional Information
Reviews (0)

Product Description

SPECIFICATIONS
Brand	ASUS
Series	ROG STRIX
Model	ROG Strix X870E-E Gaming WIFI
CPU	AMD Socket AM5 for AMD Ryzen 9000 & 8000 & 7000 Series Desktop Processors
Chipset	AMD X870E
Memory	4 x DIMM slots, max. 192GB, DDR5
	Supports up to
	8000+MT/s(OC) with Ryzen 9000 Series Processors,
	8400+MT/s(OC) with Ryzen 8000 Series Processors,
	8000+MT/s(OC) with Ryzen 7000 Series Processors,
	ECC and Non-ECC Un-buffered DIMM*
	Dual Channel Memory Architecture
	Supports AMD EXTended Profiles for Overclocking (EXPO)
	NitroPath DRAM Technology
	ASUS Enhanced Memory Profile (AEMP)
	* Supported memory types, data rate (speed), and number of DRAM modules vary depending on the CPU and memory configuration, for more information please refer to CPU/Memory Support list under the Support tab of product information site or visit https://www.asus.com/support/download-center/.
	* Non-ECC, Un-buffered DDR5 Memory supports On-Die ECC function
Graphics	1 x HDMI port**
	2 x USB4 (40Gbps) ports support USB Type-C display outputs***
	* Graphics specifications may vary between CPU types. Please refer to AMD CPU specifications.
	** Supports max. 4K@60Hz as specified in HDMI 2.1.
	*** Supports max. 4K@60Hz as specified in DisplayPort 1.4a
	**** VGA resolution support depends on processors' or graphic cards' resolution.
Expansion Slots	AMD Ryzen 9000 & 8000 & 7000 Series Desktop Processors*
	1 x PCIe 5.0 x16 slots (supports x16 mode)
	AMD X870E Chipset**
	1 x PCIe 4.0 x16 slot (supports x4 mode)
	* Please check PCIe bifurcation table in support site (https://www.asus.com/support/FAQ/1037507/).
	- To ensure compatibility of the device installed, please refer to https://www.asus.com/support/ for the list of supported peripherals.
Storage	Total supports 5 x M.2 slots and 4 x SATA 6Gb/s ports*
	AMD Ryzen 9000 & 8000 & 7000 Series Desktop Processors
	M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)
	M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)**
	M.2_3 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 5.0 x4 mode)**
	AMD X870E Chipset
	M.2_4 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)
	M.2_5 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)
	4 x SATA 6Gb/s ports
	*AMD RAIDXpert2 Technology supports both PCIe RAID 0/1/5/10 and SATA RAID 0/1/5/10. RAID 5 Funciton is only supportted by AMD Ryzen 9000series CPU.
	** M.2_2 & M.2_3 slots share bandwidth with PCIEX16(G5). When M.2_2 & M.2_3 are occupied with SSD devices, PCIEX16(G5) will run x8 only.
Ethernet	1 x Realtek 5Gb Ethernet
Ethernet	ASUS LANGuard
Wireless & Bluetooth	Wi-Fi 7*
	2x2 Wi-Fi 7 (802.11be)
	Supports 2.4/5/6GHz frequency band**
	Support Wi-Fi 7 320MHz bandwidth, up to 6.5Gbpstransfer rate.
	Bluetooth v5.4***
	*Wi-Fi features may vary depending on the operating system
	For Windows 11, Wi-Fi 7 will require24H2 or later version for full functions, Windows 11 21H2/22H2/23H2 only support Wi-Fi 6E.
	For Windows 10, please note that no driver is available, refer to the Wi-Fi chipset vendor's website for details.
	** Wi-Fi 6GHz frequency band and bandwidth regulatory may vary between countries.
	*** The Bluetooth version may vary, please refer to the Wi-Fi module manufacturer's website for the latest specifications."
USB	Rear USB (Total 13 ports)
	2 x USB4 (40Gbps) ports(2 x USB Type-C)
	1 x USB 20Gbps port (1 x USB Type-C with up to 30W PD Fast-charge)**
	10 x USB 10Gbps ports (9 x Type-A + 1 x USB Type-C)
	Front USB (Total 11 ports)
	1 x USB 20Gbps connector (supports USB Type-C)
	2 x USB 5Gbps headers support additional 4 USB 5Gbps ports
	3 x USB 2.0 headers support additional 6 USB 2.0 ports
	* USB Type-C power delivery output: 5V/3A
	** USB Type-C power delivery output: 5V/9V max. 3A, 12V max 2.5A, 15V max. 2.0A
Audio	ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080*
	- Impedance sense for front and rear headphone outputs
	- Supports: Jack-detection, Multi-streaming, Front Panel MIC Jack-retasking
	- High quality 120 dB SNR stereo playback output and 110 dB SNR recording input
	- Supports up to 32-Bit/384 kHz playback
	Audio Features
	- Audio Shielding
	- Savitech SV3H712 AMP
	- Gold-plated audio jacks
	- Rear optical S/PDIF out port
	- Premium audio capacitors
	- Audio cover
	* The LINE OUT port on the rear panel does not support spatial audio. If you wish to use spatial audio, make sure to connect your audio output device to the audio jack on the front panel of your chassis or use a USB interface audio device.
Back Panel I/O Ports	2 x USB4 (40Gbps) ports (2 x USB Type-C)
	1 x USB 20Gbps port (1 x USB Type-C with up to 30W PD Fast-charge)
	10 x USB 10Gbps ports (9 x Type-A + 1 x USB Type-C)
	1 x HDMI port
	1 x Wi-Fi Module
	1 x Realtek 5Gb Ethernet
	2 x Gold-plated audio jacks
	1 x Optical S/PDIF out port
	1 x BIOS FlashBack button
	1 x Clear CMOS button
Internal I/O Connectors	Fan and Cooling related
	1 x 4-pin CPU Fan header
	1 x 4-pin CPU OPT Fan header
	1 x 4-pin AIO Pump header
	5 x 4-pin Chassis Fan headers
	Power related
	1 x 24-pin Main Power connector
	2 x 8-pin +12V CPU Power connectors
	Storage related
	5 x M.2 slots (Key M)
	4 x SATA 6Gb/s ports
	USB
	1 x USB 20Gbps connector (supports USB Type-C)
	2 x USB 5Gbps headers support additional 4 USB 5Gbps ports
	3 x USB 2.0 headers support additional 6 USB 2.0 ports
	Miscellaneous
	3 x Addressable Gen 2 headers
	1 x CPU Over Voltage jumper
	1 x FlexKey button
	1 x Front Panel Audio header (F_AUDIO)
	1 x Start button
	1 x 10-1 pin System Panel header
	1 x Thermal Sensor header
Special Features	Extreme Engine Digi+
	- 5K Black Metallic Capacitors
	ASUS Q-Design
	- M.2 Q-Latch
	- M.2 Q-Release
	- M.2 Q-Slide
	- PCIe Slot Q-Release Slim (with PCIe SafeSlot)
	- Q-Antenna
	- Q-Code
	- Q-Dashboard
	- Q-DIMM
	- Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green])
	- Q-Slot
	ASUS Thermal Solution
	- M.2 heatsinks
	- M.2 heatsink backplate
	- VRM heatsink design
	ASUS EZ DIY
	- BIOS FlashBack button
	- BIOS FlashBack LED
	- Clear CMOS button
	- ProCool II
	- Pre-mounted I/O shield
	- SafeSlot
	- SafeDIMM
	Aura Sync
	- Addressable Gen 2 headers
BIOS	256 Mb Flash ROM
BIOS	UEFI AMI BIOS
Form Factor	ATX Form Factor
Form Factor	30.5 cm x 24.4 cm
Warranty Information
Warranty	3 Year Warranty
