| SPECIFICATIONS | |
| Brand | Fractal Design |
| Series | Celsius+ |
| Model | S28 Dynamic Edition (FD-W-2-S2801) |
| Specifications | |
| Supported Sockets | Intel: 1700 / 1200 / 1150 / 1155 / 1156 / 1366 / 2011 / 2011-3 / 2066 |
| AMD: AM2 / AM2 / AM3 / AM3 / AM4 / AM5 / FM1 / FM2 / FM2 / TR4 (via included bracket in AMD Threadripper box) | |
| Coldplate Material | Copper |
| Thermal Paste | Pre-Applied |
| Block Height | 45 mm |
| Block Measurements | 86 x 75 mm (with fittings) |
| Block Diameter | 62 mm (main block body) |
| Fan Control | Dual mode (Auto/PWM) |
| Pump | |
| Rotational Speed | 3600 RPM (max) |
| Bearing Type | Ceramic bearing and shaft |
| PWM Control | Yes |
| Acoustical Noise | 20 dBA (full speed) |
| Maximum Pressure, 50°C | 1.46 mmH2O |
| Input Voltage | 12V DC |
| Input Current | 0.36A (without fans) |
| MTTF | 50,000 hours |
| Tubes | |
| Length | 400 mm |
| Material | Low-permeability rubber with braided nylon sleeves |
| Fittings | |
| Block Side | Articulating 90-degree elbow |
| Radiator Side | Fixed |
| Fan Specifications | |
| Fan Type | Dynamic X2 GP-14 PWM |
| Rotational Speed | 500 - 1700 RPM |
| Bearing Type | LLS (Long Life Sleeve) |
| PWM Control | Yes |
| Acoustical Noise | 33.7 dBA (max) |
| Airflow | 105.9 CFM (max) |
| Static Pressure | 1.95 mmH2O (max) |
| Input Voltage | 12V DC |
| input Current | 0.25A (max) |
| MTBF | 100,000 hours |
| Radiator Specification | |
| Dimensions | 143 x 30 x 324 mm |
| Housing Material | Aluminium |
| Fin Material | Aluminium |
| Fan Screw Threads | 6 - 32 |
| General | |
| Features | Tinted glass pump face with backlit logo and ARGB LED effects |
| Smart auto control mode dynamically adjusts fan and pump speeds for the ideal balance of silence and cooling performance | |
| Twist the pump face to change from auto to PWM mode for full user control | |
| ARGB-enabled PWM hub places all fan connections directly on the radiator for a clutter-free installation | |
| Sleeved tubing with concealed wiring connects power and ARGB for the entire system at the pump | |
| Asus AURA, Gigabyte Fusion, MSI Mystic Light, and ASRock Polychrome support | |
| Pre-applied thermal paste guarantees optimal application with even coverage | |
| Low-permeability rubber tubing with nylon braided sleeves for extra durability and an added touch of style | |
| Articulating elbow fittings make tubes easier to route while reducing tension on the pump | |
| High-performance Dynamic X2 PWM fans provide excellent airflow with minimal noise (Dynamic versions only) | |
| Optimized fan geometry balances airflow with extra emphasis on static pressure (Dynamic versions only) | |
| Strategic blade notches diffuse noise from blade/stator interaction (Dynamic versions only) | |
| Trip Wire technology reduces blade turbulence (Dynamic versions only) | |
| LLS (Long Life Sleeve) fan bearings provide silent operation with a long lifespan | |
| Package Contents | Celsius+ S28 Unit |
| 2x 140 mm fans | |
| User Manual | |
| Mounting hardware for all listed sockets | |
| Fan and radiator mounting screws | |
| Warranty Information | |
| Warranty | 5 Year Warranty |
| Manufacturer's Site | Visit the manufacturer's website |
|---|---|
| Product Link | Visit the manufacturer's page for this product |
- Quiet and easy to use - Michael, 29 November 2025
Really liked the built in hub on the rad for the fans reducing cables in the system. The block was a little difficult to install as it was rather tight on my AM4 system but managed to get the screw to catch and temps have dropped quite a bit compared to my 120mm AIO I had beforehand.
The only issue was the rubberized block was super sticky like the product had been sitting for a very long time or in very warm conditions which degraded the rubber. My PS2 remote rubbers went sticky like that so maybe something to just check.
All-in-all a great AIO that is easy to set up and use. - Fractal Design FD-W-2-S2801 Early Review - Carl, 12 September 2021
This is a little bit early to review the product seeing as I have only been using it for a short while. So far so good.
Just want to point out to prospective buyers - the RGB on the pump is not controlled by software but directly by motherboard so you will need your motherboard software to control it.
The pipes are also quite thick when compared to Corsair liquid coolers so it may cause clearance issues with smaller cases. - The best AM4 bracket! lol - Dean, 28 May 2021
Initially I bought this just for the AM4 bracket that didn't come with my previous cooler.
But I can't ignore how awesome this cooler is and the cable management is a pleasure, so I just replaced my previous cooler entirely.
Great aesthetic and clean setup! - Excellent AIO - Julian, 21 April 2021
This is an excellent all in one prefilled cooler! Very easy to install on my system with the simple twist bracket on the block and fan headers on the radiator makes it easy for cable management!
Super quiet when on Auto mode and just a simple twist on the on the pump knob to put it in a Highly effective PWM mode!
Thank for stocking Fractal Wootware, Awesome products! - Keeps cool and quiet under pressue - Marthinus, 22 March 2021
Easy enough to assemble and install for AMD AM4. Subtle touch of colour just enough so I'm glad I didn't go for the RGB fan version. Sturdy materials and construction. Pairs great with Fractal Design Meshify 2. Overall worth the price.
- Fantastic cooler - Dewald, 8 June 2020
Fitted the cooler with no hassles, cables are also very well managed, build quality seems very good. Managed to do a front mounted push/ pull setup with two more Fractal fans. Conveniently Fractal uses the same thread across their products, so I was able to use some of the Define R6's HDD screws to attach the extra fans as there are no extra screws included. Temps are very good, about 20c cooler than on my big tower air cooler, 6700K @ 4.4ghz ~ 42c under load . The system is inaudible when lightly used and no where near what I would consider loud when under full load. The pump's RGB defaults to white when not controlled which works perfectly with my build.
The only down side is logging in to find the cooler is now R400 cheaper than last week when I bought mine, sigh, oh well. Makes it an even better buy.
Wootware' s service was fantastic as always! - Silent and Cool - Wolvebain, 23 May 2020
Amazing cooling performance at near silent operation.
Video of running 'noise' of system - Recorded on my Samung Note 10 Plus; crazy sensitive mic. Pics up my Dogos barking outside in the front yard, and my breathing:
https://youtu.be/9Oyhv6G4LV4
