| SPECIFICATIONS | |
| Brand | Hikvision |
| Series | Smart PoE Switch |
| Model | DS-3E1309P-EI |
| Networking | |
| Ports | 8 x 10/100 Mbps PoE Port |
| 1 x Gigabit RJ45 Port | |
| MAC Address Table | 8 K |
| Internal Cache | 4 Mbits |
| Packet Forwarding Rate | Whole-Device Performance: 4.17 Mpps |
| Port Performance: 2.68 Mpps | |
| Switching Capacity | Whole-Device Performance: 5.6 Gbps |
| Port Performance: 3.6 Gbps | |
| PoE | |
| PoE Standard | IEEE 802.3af |
| IEEE 802.3at | |
| PoE Ports | Ports 1 To 8 |
| Max. Port Power | 30 W |
| PoE Power Budget | 110 W |
| PoE Power Pin | 8-Pin Power: 1/2(-), 3/6(+), 4/5(+), 7/8(-) |
| Long Range PoE Transmission | Up To 300 m (Ports 1 To 8) |
| Switching Features | |
| VLAN Support | 802.1Q |
| VLAN ID Range | 1-4094 |
| VLAN Modes | Trunk |
| Access | |
| STP Support | 802.1D STP |
| RSTP Support | 802.1w RSTP |
| Loop Prevention | Supported (Disabled By Default) |
| Port Isolation | Ports 1 To 8 |
| PoE Watchdog | Ports 1 To 8 |
| Cable Detection | Supported |
| LLDP | 802.1ab |
| Port Mirroring | Supported |
| Management | |
| Web Management | Supported |
| DHCP Client | Supported (Enabled By Default) |
| Super IP | 10.180.190.200 |
| Hik-Central Pro | Supported |
| Hik-Partner Pro | Supported |
| Hik-Partner Pro Functions | Display Port Rate |
| Display Port Bandwidth Utilization Rate | |
| Display PoE Power Usage | |
| Display Topology Information | |
| Display Alarm Status | |
| Restart Ports And Devices | |
| Enable Port Long-Range Mode | |
| Remotely Upgrade Device | |
| Power | |
| Power Supply | 54 VDC, 2.22 A |
| Max. Power Consumption | 120 W |
| Power Consumption In Idle | 10 W |
| Surge Protection | 6 kV |
| Build & Installation | |
| Shell | Metal Material |
| Cooling | Fan-Free Design |
| Installation Mode | Desk-Mounted |
| Wall-Mounted | |
| Environmental | |
| Operating Temperature | 0 °C To 40 °C |
| Storage Temperature | -40 °C To 85 °C |
| Operating Humidity | 5% To 95% (No Condensation) |
| Relative Humidity | 5% To 95% (No Condensation) |
| Physical | |
| Dimensions (W x H x D) | 170.00 mm x 27.60 mm x 93.10 mm |
| Net Weight | 0.35 kg |
| Gross Weight | 1.114 kg |
| Compliance | |
| EMC | CE-EMC |
| IC (ICES-003: Issue 7:2020) | |
| RCM (AS/NZS CISPR 32: 2015) | |
| Safety | CB |
| CE-LVD | |
| Chemistry | CE-RoHS |
| WEEE | |
| Reach | |
| Warranty Information | |
| Warranty | 1 Year Warranty |
| Manufacturer's Site | Visit the manufacturer's website |
|---|---|
| Product Link | Visit the manufacturer's page for this product |
