| SPECIFICATIONS | |
| Brand | TP-Link |
| Series | SOHO Switches |
| Model | TL-SX1008 |
| Hardware Features | |
| Standards and Protocols | IEEE 802.3, 802.3u, 802.3ab, 802.3x, 802.1p, 802.3an, 802.3bz |
| Interface | 8 x 100Mbps / 1Gbps / 2.5Gbps / 5Gbps / 10Gbps Ports, Auto-Negotiation, Auto-MDI/MDIX |
| Fan Quantity | 1 (Intelligent Fan Speed Adjustment) |
| External Power Supply | 100–240 VAC, 50/60 Hz, 0.8A |
| LED | System Power: 1, Link/Act Indicators: 8, 1 Indicator Per Port Built Into Each RJ-45 Port |
| Dimensions (W x D x H) | 294 x 180 x 44 mm |
| Max. Power Consumption | 31.2 W |
| Performance | |
| Switching Capacity | 160 Gbps |
| Packet Forwarding Rate | 119.0 Mpps |
| MAC Address Table | 32 K |
| Packet Buffer Memory | 2 Mb |
| Jumbo Frame | 10 KB |
| Software Features | |
| Advanced Features | 802.3X Flow Control, 802.1p/DSCP QoS |
| Transmission Method | Store and Forward |
| Environmental and Packaging | |
| Certification | CE, FCC, RoHS |
| Package Content | 8-Port 10G Multi-Gigabit Desktop/Rackmount Switch TL-SX1008, Power Cord, Installation Guide, Rackmount Kit, Rubber Feet |
| Operating Temperature | 0–50 °C (32–122 °F) |
| Storage Temperature | -40–70 °C (-40–158 °F) |
| Operating Humidity | 10–90% RH Non-Condensing |
| Storage Humidity | 5–90% RH Non-Condensing |
| Warranty Information | |
| Warranty | 1 Year Warranty |
| Manufacturer's Site | Visit the manufacturer's website |
|---|---|
| Product Link | Visit the manufacturer's page for this product |
