| SPECIFICATIONS | |
| Brand | J5Create |
| Series | Docking Station Series |
| Model | JCD397 |
| General | |
| Host Connector | 1x USB-C Male |
| Video Output | 2x HDMI Female |
| 1x DisplayPort Female | |
| Power Source | Bus-Powered or Self-Powered |
| Network Interface | RJ45 (Gigabit Ethernet) |
| Audio Supported | Yes |
| Ports | 1x USB Type-C 10Gbps |
| 1x USB Type-C 5Gbps With Power Delivery 3.0 | |
| 2x USB Type-A 10Gbps | |
| 1x USB-C Power Delivery 3.0 | |
| 2x 4K HDMI | |
| 1x DisplayPort | |
| 1x SD & MicroSD 4.0 Memory Card Reader/Writer | |
| 1x RJ45 Gigabit Ethernet | |
| Performance | |
| Maximum Display Resolution | 3840 x 2160 |
| Maximum Display Refresh Rate | Windows (MST) |
| 3840 x 2160 @ 60 Hz | |
| 2560 x 1440 @ 120 Hz | |
| 1920 x 1080 @ 144 Hz | |
| Maximum Data Transfer Rate | 10Gbps |
| Displays Supported | 3 |
| Compatible Networks | 10/100/1000 Mbps |
| Audio Channel | 2.1 via HDMI |
| Features | Advanced USB Type-C E-Mark Chip Integrates USB4, Thunderbolt 3 and Thunderbolt 4 Compatibility |
| Backward Compatible With USB 3.2/3.1 | |
| Three SuperSpeed USB 10Gbps Downstream Ports (1x USB Type-C and 2x Type-A) To Connect Peripherals | |
| Charge And Power Connected Laptop And Peripherals With 100W Power Delivery | |
| SD & MicroSD 4.0 Memory Card Reader/Writer For Media Storage And Transfer | |
| Easily Add A Wired Network Connectivity With The Gigabit Ethernet Port | |
| Plug And Play, No Driver Installation Required | |
| Extending One Display Up to 3840 x 2160 @ 60, Easily Switch To A Higher Refresh Rate Of 2560 x 1440 @ 144 Via HDMI Or 1920 x 1080 @ 240 Via DP Port To Enjoy Your Gaming Under Windows OS | |
| Supports Dual 4K 60 Hz Or Triple 4K 30 Hz (2x HDMI and 1x DisplayPort) On Compatible USB Type-C Laptops With DisplayPort 1.4 Alt Mode With MST Support | |
| Power | |
| Power Delivery | Up to 100W via USB-C |
| Power Consumption | ≤ 650 mA |
| Input Current | Up to 5A |
| Input Voltage | Up to 20V |
| Output Current | Up to 4.25A |
| Output Voltage | Up to 20V |
| Colour | Space Grey |
| Enclosure Type | Aluminium |
| Cable Length | 20cm |
| Product Dimensions(L x W x H) | 148 x 55 x 17mm |
| Weight | 123.5g |
| Storage Temperature | -17 to 68°C |
| Storage Humidity | < 85% Non-Condensing |
| Operating Temperature | -1 to 41°C |
| Operating Humidity | < 85% Non-Condensing |
| Warranty Information | |
| Warranty | 2 Year Warranty |
| Manufacturer's Site | Visit the manufacturer's website |
|---|---|
| Product Link | Visit the manufacturer's page for this product |
- Really nice product. High refresh rate from DP - David, 12 October 2022
Really enjoying this dock. the cable could be longer, but that's fine. The DP has a nice refresh rate of 144hz at 2k which was the main reason for getting this. all other ports seem to be working as expected.
