| SPECIFICATIONS | |
| Brand | Phanteks |
| Series | Evolv |
| Model | Evolv Shift 2 (PH-ES217E_BK02) |
| Physical Details | |
| Colour | Satin Black |
| Materials | Steel Chassis |
| Anodized Aluminium Front & Rear Panels | |
| Side Panels | Tempered Glass |
| Front I/O Ports | 2x USB 3.0 Type-A (located on bottom front) |
| Power Button (located on top) | |
| D-RGB Colour Button | |
| D-RGB Mode Button | |
| Connectors | Power Switch |
| USB 3.0 | |
| SATA | |
| D-RGB Expansion | |
| D-RGB Third-Party | |
| D-RGB Motherboard | |
| Motherboard Support | Mini-ITX |
| Expansion Slots | 2 |
| Drive Bays | 1x 3.5" (1x included) |
| 4x 2.5" (2x included, one dual SSD bracket) | |
| PSU Support | SFX, SFX-L |
| Dimensions | 170 x 490 x 274mm (WxHxD) |
| Weight | 6.8kg (net) |
| 7.8kg (gross) | |
| Pre-Installed Fans | |
| Rear | 1x SK 140mm D-RGB PWM Fan Included |
| Fan Support | |
| Bottom | 1x 120mm | 1x 140mm |
| Rear | 2x 120mm | 2x 140mm |
| Radiator Support | |
| Rear | 1x 120mm |
| Clearance | |
| GPU Length Limitation | 335mm |
| GPU Cooler | Up to 2.9 Slots, 59mm Thickness |
| GPU Width | Up to 150mm |
| CPU Cooler Height | 85mm |
| Rear 120 Radiator | Up to 157 x 148mm |
| Thickness Up to 45mm with SFX PSU, 30mm with SFX-L PSU | |
| General | |
| Dust Filters | Top (fixed) |
| Bottom (removable) | |
| Riser Cable | PCI-E 3.0 x16 |
| Features | Small footprint, high performance |
| Vertical design | |
| 3mm Thick anodized Aluminium | |
| 360° Access to all hardware components | |
| Compact, yet powerful | |
| Ready for next gen GPU's (up to 2.9 slots) | |
| High-performance cooling | |
| Nylon mesh fabric side panels | |
| Simple push-and-release top panel design | |
| Concealed rear I/O cables for clean aesthetics | |
| Package Contents | 1x Evolv Shift 2 Chassis |
| 1x SK 140mm D-RGB PWM Fan | |
| 1x Dual 2.5" SSD Bracket | |
| 6x Zip Ties | |
| 1x Accessory Bag with Necessary Screws & Standoffs | |
| Warranty Information | |
| Warranty | 5 Year Limited Warranty |
| Manufacturer's Site | Visit the manufacturer's website |
|---|---|
| Product Link | Visit the manufacturer's page for this product |
- Amazing case that lacks some items. - Paul, 20 May 2022
Overall the case is amazing but here are some points.
- DO NOT USE PCPARTPICKER to check what PSU would fit. I used the website and it listed a ATX EVGA PSU that did not fit. TRUST ME you need a SFX power supply.
- YOU MUST GET Phanteks 4-Pin Fan Y-Splitter. This was weird as it is listed as an optional extra but the way the board is set up it is a must so don't forget to order one along with the case.(2 if you have a AIO)
- On Phanteks website they list you can install up to 4x140mm fans. 2 is the most I got along with 1 for the AIO. 3x140mm if no AIO so that is all that you would need.
- If you stand it vertical you HAVE TO pick it up from the bottom. Years of having normal cases got me use to picking a case up by just grabbing the sides. YOU CAN'T DO THAT with this case. The side panels will literally fall off and you will damage something so just bare that in mind.
- AIO tubing rerouting gave me heart failure. I had 400mm of tubing using NZXT KRAKEN. I think 300mm would be more than sufficient and save you a lot of space inside of the case.
- So you can have 1x3.5 and 2x2.5 inch drives out of the box. If you want 4x2.5 inch drives you have to buy the OPTIONAL EXTRA drive bay that will replace the 3.5 inch drives space. So bare that in mind.
- DRGB controller is crap. Get a motherboard that supports RGB settings.
- If you are wondering how much space it takes up think height wise it is the same as a normal office computer case but it takes up half the space horizontally. Definitely worth it.
- If you place your case underneath a desk you will love the IO because it comes out the top. I found this amazing.
Good case worth the money just be ready to build.
